| Ref | Part Number | Description |
|---|
| CL |
515175801 |
Female Housing, 24 Circuits |
| CL |
515175802 |
Retainer Block |
| CL |
515175803 |
Wire Seal |
| CL |
515175806 |
Female Terminal |
| CL |
515175812 |
Plug |
| CL |
710000399 |
Female Housing |
| CL |
710001131 |
Female Terminal |
| CTG1 |
278000632 |
Female Terminal |
| CTG1 |
278002896 |
Housing, 6 Circuits |
| CTG1 |
293000052 |
Sealing Cap |
| CTG1 |
515175678 |
Male Wedge, 6 Circuits |
| DIC1 |
710001223 |
Terminal |
| DIC1 |
710001224 |
Terminal |
| DIC1 |
710001225 |
Cap |
| DIC1 |
710001227 |
Housing |
| DIC1 |
710001233 |
Seal |
| DIC1 |
710001332 |
Seal Wire |
| DIC2 |
278002186 |
Wire Seal |
| DIC2 |
710001856 |
Housing |
| DIC2 |
710001857 |
Terminal |
| DIC2 |
710001859 |
Terminal |
| DIC2 |
710002075 |
Plug |
| DIC2 |
710003153 |
Seal |
| DIC3 |
710001223 |
Terminal |
| DIC3 |
710001224 |
Terminal |
| DIC3 |
710001225 |
Cap |
| DIC3 |
710001231 |
Housing |
| DIC3 |
710001233 |
Seal |
| DIC3 |
710001332 |
Seal Wire |
| FG1 |
278000632 |
Female Terminal |
| FG1 |
278001665 |
Female Terminal |
| FG1 |
278002896 |
Housing, 6 Circuits |
| FG1 |
293000052 |
Sealing Cap |
| FG1 |
515175678 |
Male Wedge, 6 Circuits |
| FLF |
409209500 |
Female Housing, 2 Circuits |
| FLF |
515176621 |
Wire Seal |
| FLF |
710001340 |
Female Terminal |
| FLS1 |
710000082 |
Female Terminal |
| FLS2 |
409010700 |
Female Terminal |
| FRF |
409209500 |
Female Housing, 2 Circuits |
| FRF |
515176621 |
Wire Seal |
| FRF |
710001340 |
Female Terminal |
| FRS1 |
710000082 |
Female Terminal |
| FRS2 |
409010700 |
Female Terminal |
| LDL |
409209400 |
Male Terminal Housing, 2 Circuits |
| LDL |
515176164 |
Male Terminal |
| LDL |
515176621 |
Wire Seal |
| LHL |
278001013 |
Wire Seal |
| LHL |
278001014 |
Female Terminal |
| LHL |
710000780 |
Connector |
| RDL |
409209400 |
Male Terminal Housing, 2 Circuits |
| RDL |
515176164 |
Male Terminal |
| RDL |
515176621 |
Wire Seal |
| RHL |
278001013 |
Wire Seal |
| RHL |
278001014 |
Female Terminal |
| RHL |
409013700 |
Plug |
| RHL |
710000780 |
Connector |
| T1 |
710002896 |
Tie-Rap Clip |
| T8 |
710002896 |
Tie-Rap Clip |
| WM1 |
278001007 |
Insulated Sheath |
| WM1 |
710000421 |
Female Terminal |
| WM2 |
278001008 |
Insulated Sheath |
| WM2 |
278002261 |
Female Terminal |
| WPM |
278000632 |
Female Terminal |
| WPM |
278002377 |
Female Terminal Housing, 12 Circuits |
| WPM |
515175679 |
FEMALE LOCK, 12 CIRCUITS - Call your local BRP dealership |
