| Ref | Part Number | Description |
|---|
| 6 |
0330131 |
CLAMP, Fuel filter |
| 7 |
0319682 |
VIS, capteur vers plaque |
| 8 |
0392376 |
FLOAT CHAMBER ASSY. This part replaces 0393784. |
| 14 |
0308776 |
O-RING |
| 15 |
0317330 |
ORIFICE PLUG |
| 15 |
0322996 |
ORIFICE 2.6 No. 70C |
| 15 |
0324389 |
ORFICIE PLUG 175 only |
| 16 |
0338884 |
GASKET, Float bowl This part replaces 0323784. |
| 18 |
0383437 |
FLOAT ASSEMBLY |
| 22 |
0336842 |
CLIP, SPRING This part replaces 0603145. |
| 23 |
0330056 |
ROLLER, Cam follower |
| 24 |
0327707 |
GASKET, Air silencer |
| 0394741 |
0394741 |
CARB ASSY., Lower 150 |
| 0394742 |
0394742 |
CARB ASSY., Middle 150 |
| 0395464 |
0395464 |
CARB ASSY., Middle 2.6 |
| 0395465 |
0395465 |
CARB ASSY., Lower 2.6 |
| 0397218 |
0397218 |
CARB ASSY., UPPER & LOWER 150 8520 |
| 0397219 |
0397219 |
CARB ASSY., MIDDLE 150 8520 |
