| Ref | Part Number | Description |
|---|
| 2 |
518327487 |
Front Suspension Support This part replaces 518325925. |
| 3 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 4 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 5 |
293150144 |
Stavex Rivet |
| 6 |
293150091 |
Henrob Rivet |
| 7 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 8 |
210262050 |
Hexagonal Head Screw This part replaces 210262080. |
| 9 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 10 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 11 |
293150179 |
MONOBOLT RIVET 4.8 - Call your local BRP dealership This part replaces 293150175. |
| 12 |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
