| Ref | Part Number | Description |
|---|
| 3 |
0393620 |
CRANKCASE HEAD & BRG. ASSY. |
| 8 |
0328582 |
CRANKSHAFT ASSY. |
| 9 |
0326749 |
SEAL RING |
| 12 |
5007695 |
CRANKCASE HEAD Assembly, Lower This part replaces 0393613. |
| 15 |
5007190 |
BEARING Assembly, Center main This part replaces 0387041. |
| 16 |
0326047 |
Retaining Ring |
| 17 |
0434844 |
BEARING, Wrist pin This part replaces 0391480. |
| 18 |
0394488 |
CONNECTING RD ASSY. |
| 20 |
0396041 |
BEARING, Connecting rod |
| 21 |
0352960 |
BEARING RACE, Center main This part replaces 0320499. |
| 22 |
0431844 |
RING SET, 0.0030 in. o.s. |
| 22 |
0431870 |
RING SET, Standard |
| 23 |
5006675 |
Piston&Ring Kt This part replaces 0432969. |
| 23 |
5006676 |
Piston&Ring Kt This part replaces 0432970. |
| 23 |
5006677 |
Pstn&Rng Kt.030 Os This part replaces 0433003. |
| 23 |
5006678 |
Pstn&Rng Kt.030 Os This part replaces 0433004. |
| 27 |
0314416 |
BUMBER, Advance screw |
| 29 |
0334317 |
STOP BRACKET |
| 30 |
0318660 |
BUMPER, Screw, throttle stop |
| 32 |
0329894 |
SCREW |
| 33 |
0331635 |
SCREW, Idle stop |
