| Ref | Part Number | Description |
|---|
| 1b |
293450275 |
Insert This part replaces 415107300. |
| 2 |
293350115 |
Ball Bearing This part replaces 293350055. |
| 4 |
706000474 |
INTERNAL BUSHING - Call your local BRP dealership |
| 5 |
293550010 |
Synthetic Grease, 400 G |
| 6 |
503191435 |
WASHER - Call your local BRP dealership |
| 7 |
232021486 |
HEX. NUT M12 - Call your local BRP dealership |
| 8 |
706000486 |
BUSHING - Call your local BRP dealership |
| 9 |
503191435 |
WASHER - Call your local BRP dealership |
| 10 |
232021486 |
HEX. NUT M12 - Call your local BRP dealership |
| 11 |
232120434 |
HEX. JAM NUT M12 - Call your local BRP dealership |
| 12 |
506136400 |
FLAT WASHER - Call your local BRP dealership |
| 13 |
706000410 |
Spacer |
| 14 |
706000409 |
Shock Absorber Shaft |
| 15 |
706000411 |
SHOCK ABSORBER - Call your local BRP dealership |
| 16 |
706000603 |
ADJUST RING - Call your local BRP dealership |
| 17 |
706000592 |
ADJUST RING - Call your local BRP dealership |
| 18 |
706000469 |
FULL MOON SPRING - Call your local BRP dealership |
| 19 |
503191604 |
SPRING STOPPER - Call your local BRP dealership |
| 20 |
503191605 |
CAP - Call your local BRP dealership |
| 21 |
706000529 |
FULL MOON SPRING - Call your local BRP dealership |
| 22 |
706000540 |
SPACER - Call your local BRP dealership |
| 23 |
503191609 |
Urethane Cushion |
| 24 |
503191872 |
Spring Guide |
| 25 |
230604034 |
Hex. Flange Screw M10 X 140 |
| 26 |
233201434 |
Hex. Flange Elastic Nut M10 |
| 27 |
207605534 |
Hex. Flange Screw |
