THERMOSTAT KIT 40 MODELS
Parts (12)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0303398 | VIS, support This part replaces 0302030. |
| 2 | 0310058 | GASKET, Thermostat |
| 3 | 0322102 | PLATE, Support |
| 4 | 0322435 | ROULEMENT, plaque d'allumage vers support |
| 5 | 0323006 | COVER, Cylinder head |
| 6 | 0323010 | GASKET, Cover to cylinder head |
| 7 | 0323012 | SEAL, Cylinder head to cover |
| 8 | 0323013 | COVER, Thermostat |
| 9 | 0323014 | GASKET, Cylinder head cover |
| 10 | 0384444 | THERMOSTAT |
| 11 | 0387694 | SPARK PLUG, Champion UL81J |
| 0388700 | 0388700 | THERMOSTAT KIT |
