| Ref | Part Number | Description |
|---|
| 1 |
0122596 |
BEARING, Shift |
| 2 |
0122624 |
CLIP, Ball spring |
| 3 |
0122625 |
BEARING, Drive gear |
| 4 |
0122626 |
WASHER |
| 5 |
0122627 |
BEARING, Throttle arm |
| 6 |
0122628 |
SPRING, Conical |
| 7 |
0122629 |
WASHER, Retainer |
| 8 |
0122630 |
SPRING, Ball |
| 9 |
0122631 |
RING |
| 10 |
0122632 |
COLLAR |
| 11 |
0122633 |
WASHER, Wave |
| 12 |
0122634 |
SCREW, Pivot |
| 13 |
0122635 |
GEAR, Drive |
| 14 |
0122636 |
GEAR, Shift |
| 15 |
0122637 |
BALL |
| 16 |
0122638 |
LINK, Actuator |
| 17 |
0122639 |
MOUNTING BRACKET |
| 18 |
0122640 |
CLAMP, Cable |
| 19 |
0122641 |
RIVET |
| 20 |
0122642 |
SCREW, Switch mtg |
| 21 |
0122643 |
GROOVE PIN |
| 22 |
0122644 |
HOUSING, Chrome |
| 23 |
0122645 |
SIDE PLATE, Chrome |
| 24 |
0122646 |
SCREW, Control mounting |
| 25 |
0122647 |
DECAL, Forward & reverse |
| 26 |
0172737 |
ARM ASSY., Throttle |
| 27 |
0172738 |
LINKAGE ASSY |
| 28 |
0172739 |
SWITCH, Neutral start |
| 29 |
0172740 |
HANDLE ASSY |
| 31 |
0301552 |
LOCKWASHER |
| 32 |
0302677 |
SCREW |
| 33 |
0303274 |
SCREW |
| 35 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz This part replaces 0306015. |
| 36 |
0306460 |
SCREW |
| 37 |
0307395 |
LOCKWASHER, Switch mtg |
| 38 |
0308335 |
CLAMP, Coil |
| 39 |
0310095 |
E-RING, Small |
| 40 |
0311410 |
NUT |
| 41 |
0122733 |
E-RING, Large |
| 43 |
0122650 |
CASING GUIDE, Control cable |
| 44 |
0122651 |
MOUNTING PLATE, Cable |
| 45 |
0122652 |
COVER PLATE, Mounting block |
| 46 |
0122653 |
MOUNTING BLOCK, Cable |
| 47 |
0122654 |
PIN, Shift lever, control |
| 48 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz This part replaces 0306561. |
| 49 |
0308078 |
CLAMP |
| 50 |
0308691 |
SCREW |
| 53 |
0385958 |
CLAMP & SC R.,Casing guide |
| 57 |
0319682 |
VIS, capteur vers plaque |
| 59 |
0307063 |
O RING |
| 61 |
0122468 |
DASH PANEL |
| 62 |
0122529 |
SCREW, Dash panel |
| 65 |
0172648 |
LEAD ASSY |
| 66 |
0279175 |
CHOKE SWITCH ASSEMBLY |
| 68 |
0900696 |
WASHER |
| 71 |
0386947 |
IGNITION SWITCH |
| 72 |
KEY |
Ref: 73 0306559 *SCREW, Ignition switch 0306559 |
| 74 |
0379853 |
INDICATING LIGHT ASSY., Temperature |
| 79 |
0172647 |
LEAD ASSY |
| 80 |
0385700 |
INST CABLE ASSY, Long |
| 86 |
0308335 |
CLAMP, Coil |
| 87 |
0307190 |
SCR., Clamp, 10-24 x 1-1/4 |
| 88 |
0316669 |
CLAMP |
| 0172540 |
0172540 |
BINNACLE CABLE ASSY |
| 0172646 |
0172646 |
BINNACLE CABLE KIT |
| 0172654 |
0172654 |
BINNACLE CONTROL & WIRING KIT |
