01- Throttle Handle And ECM
Parts (26)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 605354964 | Throttle handle |
| 2 | 605642628 | CONNECTOR - Call your local BRP dealership |
| 3 | 512060197 | LOWER HOUSING - Call your local BRP dealership |
| 4 | 512060198 | Upper housing |
| 5 | 605627003 | Clamp |
| 6 | 293710082 | Straight fitting |
| 7 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 This part replaces 33200. |
| 8 | 293800018 | SEALANT LOCTITE 592 - Call your local BRP dealership |
| 9 | 512060085 | Throttle cable |
| 10 | 234081100 | Washer |
| 11 | 414753500 | Circlip This part replaces 31035. |
| 12 | 31038 | Circlip 5 DIN 6799(1=10pcs) - Call your local BRP dealership |
| 13 | 293550004 | Grease |
| 14 | 414115200 | Tie-Rap 180 mm This part replaces 27026. |
| 15 | 36037 | Rivet |
| 16 | 512059266 | CHOKE CABLE - Call your local BRP dealership |
| 17 | 512059094 | PLASTIC NUT - Call your local BRP dealership |
| 18 | 415080200 | HOSE, POLYURETHANE - Call your local BRP dealership |
| 19 | 513032908 | Grommet |
| 20 | 293710035 | Straight fitting |
| 21 | 572045500 | T-fitting |
| 22 | 512060057 | Calibreted module |
| 23 | 605355830 | Bracket, ECM |
| 24 | 605354596 | Hose |
| 25 | 605354601 | HOSE-FORMED - Call your local BRP dealership |
| 26 | 512059324 | Valve |
