| Ref | Part Number | Description |
|---|
| Not |
Available |
As Spare Part - |
| 1 |
5010119 |
OIL TANK ASSEMBLY, Complete |
| 8 |
5010833 |
SENDER, Oil level |
| 16 |
5009787 |
OIL CAP ASSEMBLY |
| 21 |
0356081 |
HOSE, Oil fill |
| 24 |
0329661 |
SUPPORT/BOUCHON |
| 29 |
0348838 |
CLAMP, 10.5mm |
| 31 |
0359584 |
HOSE, Oil tank to rear oil pump |
| 34 |
0358884 |
BRACKET, Oil pump |
| 39 |
0357106 |
WASHER |
| 40 |
0356901 |
MOUNT, Rubber |
| 54 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 56 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
