| Ref | Part Number | Description |
|---|
| 4 |
415127956 |
Hood Decal Kit |
| 8 |
415127624 |
Reflexion Decal Kit |
| 9 |
516001201 |
REVERSE DECAL - Call your local BRP dealership This part replaces 418001600. |
| 10 |
414995800 |
Warning Label |
| 11 |
414998500 |
Instruction Label (Hitch) |
| 12 |
516002670 |
WARNING DECAL, SECURITY BELT GUARD - Call your local BRP dealership This part replaces 516000132. |
| 13 |
516002715 |
CAUTION DECAL, AIR INTAKE - Call your local BRP dealership This part replaces 516000130. |
| 16 |
M28136 |
PLUG - Call your local BRP dealership |
| 18 |
M5340532 |
Support |
| 22 |
20037 |
Washer This part replaces M20037. |
| 23 |
414510100 |
REFLECTOR, RED - Call your local BRP dealership |
| 24 |
Not |
Available As Spare Part - Screw |
| 25 |
Not |
Available As Spare Part - Washer |
| 26 |
5344151 |
Fitting Plate This part replaces M5344151. |
| 27 |
548745 |
TONGUE WELD - Call your local BRP dealership This part replaces M548745. |
| 28 |
560309200 |
PIN-RETAINER - Call your local BRP dealership |
| 29 |
41031 |
Cotter Pin This part replaces M41031. |
| 30 |
40336 |
HEX. SCREW M8 X 20 - Call your local BRP dealership This part replaces M40336. |
| 31 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 32 |
414979400 |
Taillamp Housing |
| 33 |
414979410 |
Socket |
| 34 |
414979411 |
Rubber Damper |
| 35 |
520000758 |
Bulb This part replaces 410504000. |
| 36 |
414513700 |
Lens |
| 37 |
414516400 |
Washer - Call your local BRP dealership |
| 38 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 This part replaces M33200. |
| 39 |
209632540 |
Phillips Tapping Screw M3.9 X 25 This part replaces M40613. |
| 40 |
409010600 |
FEMALE TERMINAL - Call your local BRP dealership This part replaces M42178. |
| 41 |
409010400 |
Female Terminal Housing, 1 Circuit This part replaces M42179. |
| 42 |
207063044 |
Hex. Screw M6 X 30 |
| 45 |
222842065 |
Screw M4 x 20 |
| 46 |
517124300 |
Washer |
| 47 |
232541414 |
Elastic Stop Nut M4 |
| 48 |
414510200 |
REFLECTOR, AMBER - Call your local BRP dealership |
| 414972010 |
LH |
MIRROR - Call your local BRP dealership 414972010 |
| 414972010 |
Rétroviseur |
GA - Appelez votre concessionnaire BRP local 414972010 |
