Battery and Tray
Parts (15)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0172415 | CABLE ASSEMBLY, 5 ft |
| 1 | 0172416 | CABLE ASSEMBLY, 15 ft |
| 1 | 0172417 | CABLE ASSEMBLY, 30 ft |
| 1 | 0645-836 | Battery Bracket |
| 2 | 8475-512 | Screw M5X0.8X12 |
| 3 | 8427-502 | Hex Flanged Nut M5X0.8 |
| 4 | 8061-706 | Black, Rivet |
| 5 | 6606-852 | Battery Strip |
| 6 | 0645-835 | Starter Relay Solenoide |
| 7 | 8476-520 | Screw M5X0.8X20 |
| 8 | 1623-837 | Rubber Washer |
| 9 | 1623-764 | Expansion Nut |
| 10 | 0623-038 | Nut With Washer |
| 11 | 0645-845 | Battery YUASA YTX7L-BS |
| 12 | 0645-856 | Hardware Kit |
