| Ref | Part Number | Description |
|---|
| 4 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 5 |
0342079 |
ORIFICE, Idle passage |
| 10 |
0437287 |
COVER, Carb. body |
| 22 |
0336842 |
CLIP, SPRING |
| 36 |
0330995 |
RONDELLE, levier |
| 37 |
0337353 |
SCREW, Retainer & screen |
| 39 |
0337356 |
SCREW, Air horn to carb., side |
| 40 |
0337357 |
SCREW, Air horn to carb., top |
| 42 |
0318932 |
JOINT |
| 42 |
0342982 |
GASKET, Carb. to manifold |
| 43 |
0338914 |
AIR HORN |
| 44 |
0341402 |
RETAINER, Screen to air horn |
| 45 |
0340009 |
SCREEN, Air horn |
| 46 |
0337415 |
NUT |
| 0438791 |
0438791 |
CARBURETOR ASSY. |
| 0438792 |
0438792 |
CARBURETOR ASSY. |
