| Ref | Part Number | Description |
|---|
| 10a |
207661644 |
Hex. Flange Screw M6 X 16 |
| 10ab |
518326795 |
RH Member |
| 10ac |
518326796 |
LH Member |
| 10ae |
250300038 |
Clinch Stud |
| 10ah |
293150119 |
Hemlock Rivet, 6.5 mm |
| 10aj |
518325949 |
RH Front Member |
| 10ak |
518325950 |
LH Front Member |
| 10am |
518325951 |
Front Bottom Plate |
| 10an |
390909100 |
Avex Rivet |
| 10aq |
390909200 |
Avex Rivet |
| 10at |
518324874 |
RH Reinforcement |
| 10au |
518324875 |
LH Reinforcement |
| 10av |
518325955 |
RH SLIDE BRACKET - Call your local BRP dealership |
| 10aw |
518325956 |
LH Slide Bracket |
| 10ax |
518325973 |
RH Rear Base |
| 10ay |
518325974 |
LH Rear Base |
| 10az |
518325159 |
RH ROLLER - Call your local BRP dealership |
| 10b |
210261650 |
Hex. Flange Screw M6 X 16 |
| 10bb |
250300038 |
Clinch Stud |
| 10bc |
250300027 |
Clinch Stud M6 X 20 |
| 10bd |
518326656 |
Seal |
| 10bf |
293150144 |
Stavex Rivet |
| 10bg |
518327105 |
Rear Cap |
| 10bj |
390909200 |
Avex Rivet |
| 10bm |
293150203 |
Rivet Avibulb 3/16 |
| 10bq |
293150146 |
Henrob Rivet |
| 10br |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 10bt |
518326961 |
U-Attach |
| 10bu |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 10c |
250000512 |
Socket Screw Head 1/4-20 X 5/8'' |
| 10d |
250100140 |
Elastic Hex. Flange Nut 1/4-20 |
| 10e |
293150191 |
Monobolt Rivet, 4.8 mm |
| 10g |
250300027 |
Clinch Stud M6 X 20 |
| 10j |
518326485 |
Front Radiator This part replaces 518326486. |
| 10k |
250300027 |
Clinch Stud M6 X 20 |
| 10m |
518325559 |
RH Engine Support |
| 10p |
518326820 |
LH Stirup |
| 10q |
250000958 |
Panel Nut M5 X 0.8 |
| 10r |
293150203 |
Rivet Avibulb 3/16 |
| 10s |
293150119 |
Hemlock Rivet, 6.5 mm |
| 10t |
518326960 |
Support |
| 10u |
250000536 |
Tork Screw M6 X 18 |
| 10v |
250200039 |
Flat Washer |
| 10x |
250300027 |
Clinch Stud M6 X 20 |
| 10y |
232561414 |
Elastic Stop Nut M6 |
| 10z |
250000535 |
Torx Screw M8 X 55 |
| 30 |
390402400 |
Pop Rivet 3/16" |
| 120 |
518325782 |
RH Deflector, Black Polypropylene |
| 130 |
518325783 |
LH Deflector, Black Polypropylene |
| 140 |
293150104 |
Pop Rivet 3/16" |
| 150 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 500a |
518327460 |
Driven Pulley Support |
| 510 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 700 |
518328306 |
Front Member, S Module |
| 780 |
390402200 |
Pop Rivet 3/16" |
| 900 |
518326559 |
Rear Member |
| 910 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 1100 |
518325114 |
Upper Lateral Column Support |
| 1110 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 1120 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1200 |
518325115 |
Center Column Support |
| 1210 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 1220 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 1300a |
518326611 |
Black Rear Bumper, 154" |
| 1300b |
520000965 |
Black RH Cap |
| 1300c |
520000964 |
Black LH Cap |
| 1400 |
293730047 |
Black, Dart 8 mm |
| 1405 |
293730060 |
Black, Dart 10 mm |
