| Ref | Part Number | Description |
|---|
| 1 |
1379902 |
COVER, Valve rocker arm, right |
| 2 |
1379903 |
COVER, Valve rocker arm, left |
| 3 |
1363779 |
GASKET, Valve rocker arm cover |
| 4 |
1364099 |
SCREW, Cover to head |
| 5 |
1374405 |
COTTER PIN, 3/32 x 1-1/8" |
| 6 |
1237679 |
WAHSER,Valve rocker arm shaft |
| 7 |
1249383 |
SPRING, End |
| 8 |
1194142 |
ARM, Valve rocker |
| 9 |
1192124 |
BRACKET, Rocker arm shaft |
| 10 |
1195666 |
SCREW, Arm shaft to head |
| 11 |
0991981 |
SHAFT, Valve rocker arm and plug |
| 12 |
1237691 |
PLUG, Rocker arm shaft |
| 13 |
1353596 |
BAFFLE |
| 14 |
1370108 |
VALVE, Exhaust, standard |
| 15 |
1192817 |
KEY, Valve spring cap |
| 16 |
1192816 |
CAP, Valve spring |
| 17 |
1369982 |
SPRING, Valve |
| 18 |
1378985 |
SPRING, Shaft |
| 19 |
9419653 |
BOLT, Cylinder head |
| 20 |
0992866 |
HEAD, Cylinder |
| 21 |
9419652 |
BOLT, Cyl head, outer row & ends of inner row |
| 22 |
1370109 |
VALVE, Intake, standard |
| 23 |
G-443767 |
PIN, Cylinder head to crankcase |
| 24 |
1185648 |
PUSH ROD, Valve |
| 25 |
5232245 |
LIFTER, Hydraulic valve |
| 26 |
0901463 |
CLAMP |
| 29 |
0310901 |
BRACKET, Lift |
| 30 |
0311545 |
ELBOW |
| 31 |
0311543 |
GROMMET |
| 32 |
0311544 |
GROMMET, Port |
| 33 |
0379958 |
CAP, Oil filler |
| 34 |
0994134 |
GASKET, Head |
| 35 |
0308335 |
CLAMP, Coil |
| 36 |
0316093 |
TIE STRAP |
| 37 |
0306414 |
SCREW |
| 38 |
0306519 |
SCR,Coil clamp |
| 41 |
0311415 |
SCREW, Cable clamp |
| 43 |
0550757 |
L'WASHER,Coil term |
| 44 |
0103867 |
WASHER |
| 47 |
0311391 |
SCR,Altnr to brkt |
| 49 |
0302479 |
VIS, démarreur vers bloc cylindres-carter This part replaces 0306416. |
| 51 |
0309336 |
L'WASHER, Alternator to bracket |
| 52 |
0383447 |
BRACKET, Alternator |
| 53 |
0312310 |
SPACER, Alternator brkt |
| 54 |
0310898 |
SCREW, Belt guard mount |
| 55 |
0383443 |
ALTERNAOR ASSY., Complete |
| 56 |
0305230 |
SCREW |
| 57 |
3852218 |
BRACKET, Oil cooler This part replaces 0383448. |
| 58 |
3852217 |
COIL ASSY. Ignition This part replaces 0383444. |
| 59 |
0311711 |
LEAD, Coil to distributor |
| 60 |
0310878 |
BRACE, Alternator to pump cover |
| 62 |
0981654 |
BALLAST RESISTOR This part replaces 0383433. |
| 65 |
0201809 |
SCEW,Starter to cylinder |
| 67 |
0310889 |
CLAMP, Heat exchanger tube |
| 68 |
0380565 |
SPARK PLUG, A.c.m43s |
| 68 |
0380863 |
SPARK PLUG, Champion j-10y |
| 69 |
0306834 |
BOLT, Throttle lever retainer |
| 70 |
0206421 |
D WASHER |
| 1194143 |
1194143 |
ARM, Valve rocker |
