| Ref | Part Number | Description |
|---|
| 6 |
0324677 |
JOINT TORIQUE, mamelon, vidange inférieure |
| 8 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 26 |
0393988 |
MOTOR AND CABLE ASSY |
| 27 |
0398606 |
BRUSH & SEAL KIT |
| 27 |
0583522 |
BRUSH & SEAL KIT |
| 40 |
0360252 |
WASHER This part replaces 0306311. |
| 55 |
0321246 |
BUSHING, Shock absorber, lower |
| 72 |
0321219 |
VIS, vis de fixation |
| 80 |
0511847 |
CONNECTOR, Sender |
| 81 |
0582153 |
SENDING UNIT |
| 85 |
0582093 |
LEAD ASSY This part replaces 0582092. |
| 88 |
0582878 |
INDICATOR GAUGE ASSY. |
| 93 |
0317000 |
COLLIER, câble |
| 94 |
0329289 |
JUNCTION BOX & COVER |
| 95 |
0582191 |
COLVER & TRANSFER ASSY |
| 96 |
0329289 |
JUNCTION BOX & COVER |
| 97 |
0315004 |
FIL DE LIAISON, bornier |
| 99 |
0512066 |
CLAMP |
| 100 |
0512639 |
BASE, Junction box |
| 105 |
0582182 |
CABLE ASSY, Battery |
| 106 |
0582723 |
LEAD & FUSE ASSY |
| 108 |
0114509 |
FUSE |
| 111 |
0582186 |
CONNECTOR & LEAD |
| 113 |
0582187 |
CABLE ASSY, Trim switch & guage |
| 119 |
0582188 |
CABLE ASSY TNT MOTOR |
| 136 |
0325698 |
CONNECTOR |
| 138 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 139 |
0307708 |
RONDELLE GROWER |
| 141 |
0319682 |
VIS, capteur vers plaque |
| 0173827 |
0173827 |
POWER TILT AND TIM KIT |
| 0174181 |
0174181 |
JUNCTION BOX & GAUGE |
| 0391037 |
0391037 |
HYDRAULIC ASSY |
| 0582192 |
0582192 |
JUNCTION BOX & COVER |
