| Ref | Part Number | Description |
|---|
| 1 |
0431642 |
GEARCASE & BEARING ASSY. |
| 7 |
0341280 |
SEAL |
| 28 |
0397087 |
BEARING HOUSING SEAL ASSY. |
| 31 |
0342787 |
SEAL |
| 36 |
0436888 |
PROPELLER SHAFT ASSY. |
| 39 |
0316563 |
SCREW |
| 40 |
0332583 |
SCREW & SEAL ASSY. |
| 47 |
0335722 |
DRIVESHAFT, Lower |
| 58 |
0332120 |
SHIFT ROD |
| 59 |
5007671 |
DRIVESHAFT Assembly, Upper This part replaces 0436232. |
| 60 |
0331353 |
Seal, Impeller Housing Plate. |
| 63 |
0331998 |
SCREW, Gearcase to housing |
| 65 |
0435990 |
IMPELLER HOUSING |
| 67 |
0338742 |
COMPENSATEUR DE DÉRIVE |
| 76 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 78 |
0331188 |
O-Ring |
| 80 |
0331999 |
SCREW, Gearcase housing |
| 85 |
0382761 |
PROPELLER ,14 x 11 |
| 85 |
0383160 |
PROPELLER 14 X 19 |
| 85 |
0389510 |
PROPELLER, 13 * 19 SST |
| 85 |
0389512 |
PRO, 12-3/4 x 21 sst cupped |
| 85 |
0389788 |
PROPELLER, 12 3/4 x 21 |
| 85 |
0389792 |
PROPELLER 14 x 11 -SST |
| 85 |
0389948 |
PROPELLER, 12-3/4 x 17 - SST |
| 85 |
0389949 |
PROPELLER, 12 3/4 X 15-SST |
| 85 |
0390896 |
PROPELLER, 13 * 19 AL. |
| 85 |
0392261 |
PROPELLER 13 3/4 X 13 - SST |
| 85 |
0394755 |
PROPELLER, 13 1/2 X 24 OMC RAKER |
| 85 |
0394758 |
PROPELLER 13 1/2 X 21 SST II |
| 85 |
0394759 |
PROPELLER, 13 1/2 x 20 OMC Raker |
| 85 |
0394760 |
PROPELLER, 13 1/2 x 22 OMC Raker |
| 85 |
0765181 |
PROPELLER This part replaces 0391668. |
| 85 |
0765182 |
PROPELLER - W Models This part replaces 0391198. |
| 85 |
0765183 |
PROPELLER, WDEL Models This part replaces 0391199. |
| 89 |
5006373 |
GEARCASE SEAL KIT This part replaces 0438278. |
| 0435474 |
5000356 |
G/C Ay*Cv4&Lv4 .50 This part replaces 0435474. |
