| Ref | Part Number | Description |
|---|
| 10a1aa |
390909200 |
Avex Rivet |
| 10a1ab |
390909100 |
Avex Rivet |
| 10a1ac |
390909200 |
Avex Rivet |
| 10a1d |
605636002 |
Clinch Nut Hexsert M8 |
| 10b |
708301095 |
Linq Hole Filler |
| 10c |
293150291 |
Black, Pop Rivet 3/16 X ,425 |
| 10d |
505073670 |
Cotter Spring |
| 10f |
293750069 |
Retainer Cable |
| 10g |
293150144 |
Stavex Rivet |
| 10h |
5342952 |
Hood Latch |
| 10j |
234052450 |
Flat Washer |
| 10k |
207652044 |
Hex.Flange Screw M5 X 20 |
| 10m |
233251434 |
Flange Elastic Nut M5 |
| 10n |
414644300 |
Black, Dart |
| 10p |
705203824 |
Lashing Rings Support |
| 10q |
390909100 |
Avex Rivet |
| 10r |
707601725 |
Upper Heat Shield Wide |
| 20 |
506150400 |
Housing Half |
| 25 |
506150500 |
Housing Bushing |
| 30 |
506150600 |
Stopper Plate |
| 40 |
207787044 |
Carriage Bolt M8 X 70 |
| 50 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 60 |
705203836 |
Cargo Box Hinges Reinforcement Plate |
| 65 |
293150291 |
Black, Pop Rivet 3/16 X ,425 |
| 90 |
708301058 |
Cargo Box Gas Shock |
| 95 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 100 |
708303737 |
Black, LH Side Platform |
| 110 |
708300935 |
Hinge Axis |
| 120 |
205083044 |
Socket Head Screw M8 X 30 |
| 130 |
250000761 |
Torx Truss Screw M8 X 50 |
| 140 |
234082670 |
Stainless Steel Flat Washer |
| 190 |
708303738 |
Black, RH Side Platform |
| 201 |
205484056 |
Torx Truss M/S M8 X 40 |
| 202 |
503192494 |
Washer |
| 203 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 204 |
207686544 |
Hex. Flange Screw, M8 X 65 |
| 205a |
708302990 |
D-Ring |
| 205b |
708302991 |
Tie-Down Ring Spring |
| 205c |
708302992 |
Tie-Down Ring Bracket |
| 206 |
250001078 |
Socket Screw M6 X 35 |
| 207 |
233061414 |
Hex. Flange Nut M6 |
| 220a |
605356527 |
LH Tail Light Plate |
| 220b |
710001645 |
Tail Light Ass'y |
| 220c |
250000720 |
Torx Screw K50 X 16 |
| 220d |
710002964 |
Flasher |
| 220f |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 220g |
705016982 |
Red, Reflector |
| 220h |
233251434 |
Flange Elastic Nut M5 |
| 220j |
710008467 |
Light |
| 220k |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 230a |
605356528 |
RH Tail Light Plate |
| 230b |
710001645 |
Tail Light Ass'y |
| 230c |
250000720 |
Torx Screw K50 X 16 |
| 230d |
710002964 |
Flasher |
| 230f |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 230g |
705016982 |
Red, Reflector |
| 230h |
233251434 |
Flange Elastic Nut M5 |
| 230j |
710008467 |
Light |
| 230k |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 240 |
250000767 |
Torx Truss Screw M6 X 12 |
| 310 |
708303739 |
Black, Front Panel Short |
| 314 |
250000761 |
Torx Truss Screw M8 X 50 |
| 315 |
234082670 |
Stainless Steel Flat Washer |
| 316 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 320 |
28056 |
Cover |
| 330 |
708300939 |
Locking Handle Weld |
| 350 |
708301336 |
Bed Heat Shield On Top |
| 360 |
708301337 |
Bed Heat Shield On Side |
| 370 |
708301338 |
Side Heat Shield |
| 380 |
708302168 |
Heat Shield |
| 400a |
708300959 |
Middle Deck |
| 400b |
708301262 |
Filler Plate |
| 400c |
708301263 |
Handle Plate |
| 400d |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 500a |
708303364 |
Lower Tailgate Inner |
| 500b |
708303416 |
Register Plate Support |
| 500c |
708301213 |
Limiter Rail |
| 500d |
390909100 |
Avex Rivet |
| 500f |
605449087 |
Counter Roller |
| 500g |
293150212 |
Rivet |
