07- Body - Decals
Parts (35)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5033704 | FILTER, FUEL |
| 2 | 5033536 | HOSE Assy, FUEL |
| 3 | 5033708 | INJECTOR Assy, FUEL |
| 5 | 5030709 | INSULATOR, Delivery pipe |
| 6 | 5036041 | PIPE, DELIVERY |
| 7 | 5036606 | COOLER, FUEL |
| 8 | 5033538 | UNION, FUEL HOSE |
| 9 | 5033710 | BRACKET |
| 10 | 5031754 | TEE, Fuel |
| 10 | 516010651 | BRP Logo 20 MM x 2 MM |
| 12 | 5030466 | GASKET |
| 13 | 5030471 | SPACER |
| 14 | 5030555 | CUSHION |
| 15 | 5031139 | CUSHION |
| 15 | 704909041 | Emblem Logo BRP 68 MM UV |
| 20 | 5030567 | BOLT |
| 21 | 5030569 | UNION |
| 22 | 5030579 | CLAMP |
| 23 | 5030979 | BOLT, STUD |
| 24 | 5036601 | BOLT |
| 26 | 5031003 | BOLT |
| 30 | 704909040 | Emblem BRP Logo 48 MM UV |
| 200 | 516010363 | Upper Sidepanel Decal "600 EFI" |
| 300 | 516010629 | LH/RH Side Panel Decal "Lynx X Terrain" |
| 310 | 516010970 | LH/RH Side Panel Decal |
| 600 | 516008760 | Decal "Rotax Power" |
| 700 | 516010632 | Tunnel Decal |
| 800 | 516010635 | LH/RH Platform Decal |
| 1105 | 516011365 | Clutch Instruction Label |
| 1120 | 516011629 | Tool Instruction Label |
| 1535 | 516009954 | Protective Decal |
| 1540 | 516011681 | Decal Q-Link |
| 1550 | 516011681 | Decal Q-Link |
| 1560 | 516011681 | Decal Q-Link |
| 4720 | 516010547 | Ident. Decal |
