| Ref | Part Number | Description |
|---|
| 1 |
0397820 |
ENGINE COVER ASSY., 90 models |
| 1 |
0397821 |
ENGINE COVER ASSY., 110 models |
| 1 |
0398809 |
ENGINE COVER ASSY., 88 |
| 1 |
0432747 |
ENGINE COVER ASSY., 100STL |
| 4 |
0329548 |
SEAL This part replaces 0325435. |
| 5 |
0389971 |
LOCATING BARCKET, Front |
| 6 |
0394976 |
LOCATING BRACKET, Rear |
| 8 |
0341534 |
SOUND BLANKET, Side This part replaces 0208509. |
| 8 |
0911532 |
SOUND BLANKET, Side, 100 |
| 9 |
0208510 |
SOUND BLANKET, Top |
| 9 |
0911531 |
SOUND BLANKET, Top, 100 |
| 11 |
0323175 |
HOOK , Motor Cover, Front |
| 13 |
0331856 |
APPLIQUE, Front |
| 13 |
0334224 |
APPLIQUE, Rear, 88 models This part replaces 0333611. |
| 18 |
0332798 |
PLATE, Rear, 90 models |
| 18 |
0332799 |
PLATE, Rear, 110 models |
| 18 |
0334224 |
APPLIQUE, Rear, 88 models This part replaces 0333611. |
| 19 |
0331420 |
APPLIQUE, Engine cover |
| 21 |
0332795 |
PLATE, Applique front |
| 22 |
0432828 |
AIR INLET, Port |
| 23 |
0398445 |
AIR INLET, Star This part replaces 0432829. |
| 24 |
0378347 |
CORDE DE LANCEUR |
| 25 |
0398996 |
DECAL SET, 88 models |
| 25 |
0398997 |
DECAL SET, 90 models |
| 25 |
0398998 |
DECAL SET, 110 models |
| 25 |
0432944 |
DECAL SET, 100STL models |
| 26 |
0210957 |
OWNERS MANUAL, 90/110 This part replaces 0398930. |
| 26 |
0398934 |
OWNERS MANUAL, 88 models |
| 26 |
0431858 |
OWNERS MANUAL, 90/110 |
