| Ref | Part Number | Description |
|---|
| 1 |
0432527 |
ENGINE COVER ASSY., 150TL |
| 1 |
0432528 |
ENGINE COVER ASSY., 150CX |
| 1 |
0432577 |
ENGINE COVER ASSY., 150TLA |
| 1 |
0432756 |
ENGINE COVER ASSY., 150TX |
| 1 |
0432757 |
ENGINE COVER ASSY., 175 |
| 2 |
0394976 |
LOCATING BRACKET, Rear |
| 3 |
0389971 |
LOCATING BARCKET, Front |
| 10 |
0334615 |
PLATE, Applique, rear, 150T |
| 10 |
0334620 |
PLATE, Applique, rear, 150CX |
| 10 |
0334622 |
PLATE, Applique, rear, 175 |
| 11 |
0209445 |
SOUND BLANKET, Top |
| 12 |
0323175 |
HOOK , Motor Cover, Front |
| 14 |
0328686 |
SEAL, Engine cover |
| 15 |
0334614 |
PLATE, Front |
| 15 |
0334619 |
PLATE, Front, 150CX |
| 16 |
0334853 |
SOUND BLANKET, Side |
| 18 |
0331236 |
APPLIQUE, Engine cover, rear |
| 19 |
0331232 |
APPLIQUE, Front |
| 19 |
0331236 |
APPLIQUE, Engine cover, rear |
| 21 |
0398446 |
AIR INLET, Port |
| 22 |
0398447 |
AIR INLET, Star |
| 23 |
0378347 |
CORDE DE LANCEUR |
| 24 |
0433142 |
DECAL SET, 150 |
| 24 |
0433144 |
DECAL SET, 175 |
| 25 |
0433262 |
OWNER'S MANUAL |
| 25 |
0433263 |
OWNER MANUAL |
