| Ref | Part Number | Description |
|---|
| 1 |
0393752 |
GEARCASE & BEARING ASSY. This part replaces 0385560. |
| 5 |
0387152 |
BEARING HOUSING ASSY |
| 7 |
0317273 |
LEVER, Shift |
| 9 |
0326374 |
DETENT, Shifter This part replaces 0318532. |
| 10 |
0317276 |
DETENT, SCREW |
| 16 |
0320709 |
SHAFT, Shift dog |
| 20 |
0386282 |
PROPELLAR SHAFT ASSY. |
| 30 |
0317178 |
O RING |
| 33 |
0386122 |
DRIVENSHAFT ASSY.,Long |
| 36 |
0317231 |
SHIM, . 002" |
| 37 |
0313754 |
O RING |
| 40 |
0319545 |
VIS, supports de montage supérieurs vers support de direction |
| 45 |
0317165 |
THRUST WASHER, Fwd |
| 48 |
0385756 |
COVER ASSEMBLY |
| 50 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 52 |
0320128 |
SHIFT ROD |
| 53 |
0307151 |
SCREW |
| 55 |
0317385 |
PIN, Shift lockout |
| 58 |
0382547 |
IMPELLER ASSEMBLY |
| 59 |
0432955 |
WATER PUMP REPAIR KIT (includes impeller housing) This part replaces 0319277. |
| 61 |
0319292 |
SCREW, Clamp |
| 67 |
0307708 |
RONDELLE GROWER |
| 68 |
0306503 |
SCREW, Short |
| 70 |
0313697 |
SCR,Grc to hsg.long |
| 71 |
0306314 |
L'WASHER,Scr,long |
| 76 |
0338742 |
COMPENSATEUR DE DÉRIVE This part replaces 0316981. |
| 77 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 78 |
0382761 |
PROPELLER ,14 x 11 |
| 78 |
0382765 |
PROPELLER 13 X 19 |
| 78 |
0382766 |
PROP. 12-3/4 X 21 (STD) |
| 78 |
0383160 |
PROPELLER 14 X 19 |
| 78 |
0384136 |
PROPELLER 12-3/4 X 23 |
| 78 |
0384139 |
PROP., 13 - 3/8 x 17 - SST |
| 78 |
0384142 |
PROP., 13 x 19 - SST |
| 78 |
0384703 |
PROP, 12-3/4 x 23 sst cupped This part replaces 0384138. |
| 78 |
0389512 |
PRO, 12-3/4 x 21 sst cupped This part replaces 0384141. |
| 78 |
0765181 |
PROPELLER This part replaces 0382762. |
| 78 |
0765182 |
PROPELLER - W Models This part replaces 0382763. |
| 78 |
0765183 |
PROPELLER, WDEL Models This part replaces 0382764. |
| 79 |
0314188 |
CONVERGING RING |
| 80 |
0386533 |
WATER PUMP REPAIR KIT |
| 0387194 |
0387194 |
GEARCASE ASSY., Long |
