| Ref | Part Number | Description |
|---|
| 2 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 3 |
710000518 |
Open Barrel |
| 5 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 6 |
207162544 |
Hex. Screw M6 X 25 |
| 7 |
234461608 |
External Serrated Lock Washer 6 mm |
| 8 |
232061414 |
Hex. Nut M6 |
| 9 |
233061414 |
Hex. Flange Nut M6 |
| 13 |
Not |
Available As Spare Part - Open Barrel |
| 14 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 15 |
Not |
Available As Spare Part - Open Barrel |
| 16 |
710000497 |
PROTECTOR TUBE, 9 MM - Call your local BRP dealership |
| 17 |
710001829 |
Protector Cap |
| 19 |
710001817 |
Protector Cap |
| 21 |
710000476 |
OPEN BARREL, 6.6 MM - Call your local BRP dealership |
| 22 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 23 |
275500578 |
Shrink Tubing |
| 24 |
710000497 |
PROTECTOR TUBE, 9 MM - Call your local BRP dealership |
| 25 |
710001829 |
Protector Cap This part replaces 710000516. |
| 26 |
710001828 |
PROTECTOR CAP - Call your local BRP dealership This part replaces 710000522. |
| 27 |
710001817 |
Protector Cap This part replaces 710000902. |
| 29 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 30 |
710000497 |
PROTECTOR TUBE, 9 MM - Call your local BRP dealership |
| 31 |
710000526 |
Protector Cap |
| 32 |
710001817 |
Protector Cap |
| 32a |
XXX |
Not Available As Spare Parts |
| 33 |
232561414 |
Elastic Stop Nut M6 |
| 35 |
710000476 |
OPEN BARREL, 6.6 MM - Call your local BRP dealership |
| 36 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 37 |
710000497 |
PROTECTOR TUBE, 9 MM - Call your local BRP dealership |
| 43 |
219704398 |
Was 409901600 Tubing 19mm |
| 44 |
710000476 |
OPEN BARREL, 6.6 MM - Call your local BRP dealership |
| 45 |
219704447 |
Was 710000483 Heat Shrink Tubing |
| 46 |
515175919 |
Protector Cap |
| 48 |
234461608 |
External Serrated Lock Washer 6 mm |
| 49 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 50 |
414227300 |
Clip |
| 51 |
710007777 |
Starter Relay This part replaces 710001364. |
| 52 |
234161601 |
Lock Washer Helical M6 |
| 53 |
232061600 |
Hex. Nut M6 |
| 54 |
710001260 |
SOLENOID SUPPORT - Call your local BRP dealership |
| 55 |
207661244 |
Hex. Flange Screw M6 X 12 |
| 56 |
233061414 |
Hex. Flange Nut M6 |
| 66 |
234101601 |
Helicoidal Lock Washer M10 |
| 67 |
250000029 |
HEX. SCREW M10 X 16 - Call your local BRP dealership |
| 69 |
250000282 |
Battery Bolt Kit This part replaces 295500849. |
| 70 |
710000279 |
INSULATOR PAD - Call your local BRP dealership |
| 72 |
293850097 |
Retainer Strap |
| 73 |
293850030 |
Strap Clip |
