| Ref | Part Number | Description |
|---|
| 1 |
605348472 |
Decal, upper hood R.H. |
| 1 |
605348473 |
Decal, upper hood L.H. |
| 2 |
605348471 |
Decal, Rotax |
| 3 |
605348476 |
Front decal, hood |
| 4 |
5447014 |
Warning decal |
| 5 |
5447012 |
Oil cheking decal |
| 6 |
5447016 |
Fanbelt decal |
| 7 |
5347035 |
Dash decal |
| 8 |
5348181 |
Instruction decal |
| 9 |
516008738 |
Logo 48mm "BRP" This part replaces 516000983. |
| 10 |
21121 |
REFLECTOR (YELLOW) - Call your local BRP dealership |
| 11 |
5447929 |
Instruction decal |
| 12 |
516001720 |
Grip heat decal |
| 13 |
605448799 |
PULLING BAR DECAL - Call your local BRP dealership |
| 14 |
605448801 |
Warning decal |
| 15 |
5440839 |
Support |
| 16 |
21060 |
Front reflector white |
| 17 |
Not |
Available As Spare Part - Instruction decal - DOES NOT APPLY TO THIS MODEL |
| 18 |
414510200 |
REFLECTOR, AMBER - Call your local BRP dealership |
| 19 |
40070 |
Slot sc. M5 x 10DIN7985m4.6Zne(1=10pcs) - Call your local BRP dealership |
