| Ref | Part Number | Description |
|---|
| 1 |
0321921 |
JOINT TORIQUE |
| 2 |
0346329 |
SLEEVE, Pressure relief |
| 3 |
0346377 |
SPRING, Pressure relief |
| 4 |
0346336 |
VALVE, Blowoff |
| 6 |
5000833 |
CAP, Pressure relief valve |
| 8 |
0346110 |
HOUSING, Thermostat |
| 12 |
0346119 |
TEE, Water supply, port |
| 16 |
0346119 |
TEE, Water supply, port |
| 20 |
0346539 |
TEE, Thermostat & ECU drain |
| 23 |
0346140 |
TEE, Thermostat drain |
| 26 |
5000832 |
COVER & NIPPLE ASSY., Thermostat |
| 28 |
5005042 |
DIAPHRAGM & HOSE Assy, Exhaust This part replaces 5000949. |
| 31 |
0346540 |
HOSE, Water supply to vapor separator |
| 33 |
0437090 |
THERMOSTAT |
| 34 |
0337207 |
COVER, Thermostat |
| 35 |
0337194 |
GASKET, Thermostat cover |
| 36 |
0310058 |
GASKET, Thermostat |
| 38 |
0909533 |
SCREW, Pressure relief valve cover |
| 43 |
5001551 |
FITTING, Exhaust pressure |
| 44 |
0346527 |
GASKET, Exhaust fitting |
| 46 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
