| Ref | Part Number | Description |
|---|
| 14 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 18 |
0357023 |
DECAL, Fuse panel |
| 30 |
0514764 |
MINIFUSE, 5 Amp |
| 39 |
3011956 |
TERMINAL, Socket |
| 42 |
0503956 |
Split Convoluted Tubing Max Dia. (in.) 1/2 This part replaces 3010591. |
| 72 |
3011666 |
TUBING, Convoluted |
| 79 |
3011782 |
TERMINAL, Receptacle |
| 80 |
3011783 |
SEAL, TERMINAL |
| 86 |
3011805 |
FUSE, 3 AMP |
| 87 |
FUSE |
BLOCK, 60 Position |
| 88 |
3011787 |
COVER, Fuse Block |
| 92 |
0503956 |
Split Convoluted Tubing Max Dia. (in.) 1/2 This part replaces 3010608. |
| 100 |
0356843 |
CLIP, Mounting |
| 114 |
5009078 |
FUSE & RELAY BRACKET |
