04- Drive - Rear - Common Parts
Parts (54)
| Ref | Part Number | Description |
|---|---|---|
| 50a | XXX | Not Available As Spare Parts |
| 56a | XXX | Not Available As Spare Parts |
| 110 | 705212282 | Gearbox Support |
| 120 | 207502046 | Hex. Flange Screw M10 X 20 |
| 125 | 233201436 | Hex. Flange Elastic Nut M10 This part replaces 233201416. |
| 250a | 715500463 | Circlip Joint |
| 250b1 | 715500475 | Clamp Small |
| 250b2 | 715500476 | Clamp Large |
| 250c1 | 715500475 | Clamp Small |
| 250c2 | 715500477 | Clamp Large |
| 260a | 715500463 | Circlip Joint |
| 260b1 | 715500475 | Clamp Small |
| 260b2 | 715500476 | Clamp Large |
| 260c1 | 715500475 | Clamp Small |
| 260c2 | 715500477 | Clamp Large |
| 300 | 705503257 | Wheel Hub |
| 305 | 250300055 | Wheel Stud M10 X 1.25 |
| 320 | 293350150 | Ball Bearing |
| 325 | 293370019 | Circlip |
| 330 | 232291413 | Hex. Flange Castellated Nut M18 |
| 335 | 250200171 | Conical Spring Washer M18 |
| 340 | 250400071 | Cotter Pin |
| 515 | 705503620 | Cable Shift Lever |
| 520 | 705503818 | Gearshift Lever |
| 525 | 207664554 | Hex. Flange Screw |
| 526 | 233261466 | Hex. Flange Elastic Nut M6 |
| 528 | 707003072 | Flanged Bushing |
| 529 | 707002803 | Bushing |
| 530 | 705503817 | Front Cable Support |
| 535 | 207661646 | Hex. Flange Screw M6 X 16 |
| 540 | 233261466 | Hex. Flange Elastic Nut M6 |
| 600 | 707002804 | Torsion Spring |
| 620 | 707002805 | Gearshift Lever |
| 625 | 207664554 | Hex. Flange Screw |
| 626 | 233261466 | Hex. Flange Elastic Nut M6 |
| 628 | 707003072 | Flanged Bushing |
| 629 | 707002803 | Bushing |
| 630 | 707003177 | Shift Lever Tip |
| 635 | 232180491 | Hex. Jam Nut M8 |
| 640 | 707003633 | Trim |
| 650 | 705503596 | Shift Lever Grille |
| 655 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip |
| 660 | 705503819 | Rear Cable Support |
| 665 | 250001257 | Screw Torx M6 X 20 |
| 670 | 707002891 | Clutch Lever |
| 672 | 233261466 | Hex. Flange Elastic Nut M6 |
| 674 | 207663544 | Hex. Flange Screw M6 X 35 |
| 676 | 232581414 | Hex. Elastic Stop Nut M8 |
| 680 | 705503889 | Vibration Damper |
| 690 | 207662046 | Hex. Flange Screw M6 X 20 |
| 700 | 233261466 | Hex. Flange Elastic Nut M6 |
| 705 | 250000302 | Hex Flange Screw M8 X 65, SCOTCH GRIP - Call your local BRP dealership |
| 710 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip |
| 720 | 234082410 | Flat Washer 8 mm |
