| Ref | Part Number | Description |
|---|
| 1 |
0334241 |
GUIDE |
| 2 |
0332482 |
LEVER-SHIFT |
| 3 |
0315164 |
BALL, Shift detent |
| 4 |
0321532 |
SCREW |
| 7 |
0329241 |
RONDELLE |
| 8 |
0436201 |
CABLE |
| 9 |
0342616 |
PLUG, Shift handle |
| 10 |
0334135 |
BUSHING |
| 11 |
0319537 |
CLIP |
| 12 |
0334058 |
LEVER, Shift |
| 13 |
0334338 |
SCREW, Lever to shift rod |
| 14 |
0342608 |
BUSHING |
| 16 |
0432014 |
SHAFT Assy, Shift |
| 17 |
0342609 |
EYE, Cable end |
| 18 |
0312708 |
BUSHING |
| 21 |
0334246 |
SPACER |
| 22 |
0334057 |
LINK |
| 23 |
0908398 |
WASHER |
| 27 |
0127386 |
RONDELLE This part replaces 0303913. |
| 29 |
0304027 |
VIS, arbre de commande de sens de marche |
| 31 |
0336868 |
WASHER, Nut |
| 33 |
0331109 |
SCREW, Lever |
| 34 |
0328456 |
CLAMP |
| 35 |
0334248 |
DETENT |
| 39 |
0328731 |
VIS, câble de verrouillage |
| 42 |
0342358 |
BOLT |
| 43 |
0342613 |
NUT |
| 44 |
0342617 |
SPRING, Cable |
| 45 |
0342618 |
GUIDE TUBE |
