| Ref | Part Number | Description |
|---|
| 1 |
0318444 |
BELLCRANK, Choke |
| 3 |
0310302 |
SCREW PUMP ASSY |
| 14 |
0320287 |
ADJUSTMENT LEVER |
| 15 |
0510278 |
SCREW |
| 18 |
0314906 |
CLIP |
| 19 |
0315239 |
SPRING, Choke return |
| 20 |
0318445 |
SPRING, Choke override |
| 21 |
0309720 |
SCREW, Cam follower |
| 22 |
0323693 |
WASHER, Bellcrank screw This part replaces 0553645. |
| 23 |
0315236 |
LEVER CHOKE |
| 27 |
0318536 |
SLEEVE |
| 28 |
0315232 |
RETAINER , Needle valve stbd |
| 29 |
0388278 |
FLOAT CHAMBER |
| 31 |
0307832 |
PLUG, Screw |
| 34 |
0388885 |
NEEDLE VALVE, Slow speed |
| 36 |
0313329 |
LOCKWASHER, Carburetor link |
| 37 |
0303792 |
COVER, Solenoid |
| 38 |
0320783 |
SPRING, Plunger |
| 39 |
0377890 |
PLUNGER SOLENOID |
| 40 |
0385554 |
SOLENOID |
| 41 |
0323338 |
GASKET, Carb to silencer |
| 42 |
0316074 |
BOUCHON, couvercle de volant-moteur |
| 43 |
0323339 |
BRACKET, Support |
| 45 |
0306413 |
WASHER |
| 47 |
0325092 |
GASKET This part replaces 0314477. |
| 48 |
0316355 |
BUT, Carburetor mounting |
| 49 |
0315322 |
LINK |
| 50 |
0303739 |
PIVOT PIN |
| 51 |
0382778 |
PIN, Solenoid |
| 54 |
0322784 |
SCREW, Silencer to carb |
| 55 |
0303747 |
LEVER |
| 56 |
0388916 |
AIR SILENCER |
| 57 |
0318439 |
LINK, Throttle lever to choke bellcrank |
| 58 |
0328907 |
COLLIER, amorçage vers support This part replaces 0303740. |
| 59 |
0329594 |
SCREW, Cam follower This part replaces 0303737. |
| 60 |
0328063 |
ADJUSTING KNOB, Slow speed This part replaces 0323622. |
| 61 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz This part replaces 0306015. |
| 62 |
0204490 |
DETENT CHOKE, Ling |
| 0388978 |
0388978 |
CARBURETOR ASSY |
| 0388980 |
0388980 |
CARBURETOR ASSY |
