| Ref | Part Number | Description |
|---|
| 1 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 2 |
0393735 |
RETAINER & LINK ASSY., 8 Models only |
| 2 |
0395883 |
RETAINER & LINK ASSY., 6 models This part replaces 0392534. |
| 3 |
0583916 |
FLYWHEEL ASSEMBLY This part replaces 0582997. |
| 4 |
0322549 |
DISPOSITIF DE RETENUE, bouchon |
| 5 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 6 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 7 |
0332063 |
PLATE, Support This part replaces 0323398. |
| 9 |
0326016 |
NUT, Flywheel |
| 10 |
0332070 |
SCREW, Retaining plate This part replaces 0326875. |
| 11 |
0396141 |
POWER PACK |
| 11 |
0582800 |
POWER PACK ASSY., 8 Models only |
| 15 |
0512432 |
CONNECTER |
| 18 |
0582417 |
PLATE & SLEEVE ASSEMBLY |
| 21 |
0583387 |
SENSOR ASSEMBLY This part replaces 0581655. |
| 23 |
0303212 |
VIS, collier & capot |
| 25 |
0511460 |
VIS, dispositif de retenue |
| 26 |
0511458 |
COLLIER, fils |
| 27 |
0511459 |
CACHE, fils |
| 28 |
0512415 |
CONNECTOR |
| 29 |
0581670 |
CHARGE COIL |
| 31 |
0512765 |
BRACKET |
| 35 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 39 |
0329176 |
FIBER WASHER, Ignition coil |
| 40 |
0329110 |
VIS, boîtier d'échappement vers bloc cylindres-carter |
| 41 |
0376349 |
FIL, masse |
| 42 |
0329182 |
VIS, borne |
| 43 |
0173692 |
RECTIFIER ASSEMBLY, DC |
| 45 |
0511949 |
BORNIER |
| 46 |
0582508 |
COIL ASSY |
| 0582690 |
0582690 |
CHARGE COIL & PLATE ASSY. 6RC, 6RLC,8ROPE |
| 0582914 |
0582914 |
STATOR & PLATE ASSY |
