07- Body - Side Panels
Parts (37)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 0341913 | COVER, Cable entry |
| 6 | 0349557 | MOUNT This part replaces 0328584. |
| 7 | 5006414 | COVER Assy, Lower - Stbd This part replaces 0438488. |
| 9 | 5004759 | COVER Assy, Lower- Port This part replaces 0438487. |
| 18 | 0325115 | SCREW, Oil tank/EMM mount |
| 22 | 0349556 | Washer This part replaces 0329749. |
| 27 | 0317972 | ACREW,Exh manf to cyl.,4-1/4" long |
| 32 | 0343912 | Braided Sleeve Max Dia. (in.) 1.75 |
| 80 | 517307422 | RH Knob Part 24" |
| 145 | 517307423 | LH Knob Part 24" |
| 1000 | 517306817 | RH Side Panel 24" With Gearbox |
| 1010 | 517307408 | RH Grille |
| 1011 | 250000725 | Screw M4 X 16 |
| 1020 | 517305773 | RH Rear Latch |
| 1025 | 517305773 | RH Rear Latch |
| 1030 | 250000805 | Plastite Screw M4 X 10 |
| 1035 | 517307906 | White, RH Large Trim |
| 1070 | 517308479 | RH Front Side Panel Foam |
| 1080 | 517308480 | RH Rear Side Panel Foam |
| 1090 | 517308481 | RH Upper Side Panel Foam |
| 1092 | 517308482 | RH Central Side Panel Foam |
| 1093 | 517308483 | RH Central Side Panel Foam |
| 1094 | 517307903 | RH Side Panel Heat Shield |
| 1200 | 517307250 | LH Side Panel 24" |
| 1210 | 517306832 | LH Air Intake Grip |
| 1220 | 517305774 | LH Rear Latch |
| 1225 | 517305774 | LH Rear Latch |
| 1230 | 250000805 | Plastite Screw M4 X 10 |
| 1235 | 517307907 | Whitem LH Large Trim |
| 1270 | 517308484 | LH Front Side Panel Foam |
| 1280 | 517308485 | LH Rear Side Panel Foam |
| 1290 | 517308486 | LH Upper Side Panel Foam |
| 1300 | 517307449 | LH Snow Deflector 24" |
| 1350 | 250000721 | Torx Truss Screw M6 X 16 |
| 1400 | 517305985 | Rear Stud |
| 1420 | 250000725 | Screw M4 X 16 |
| 4400 | 517306818 | Shift Lever Grille |
