| Ref | Part Number | Description |
|---|
| 1 |
0330184 |
VIS, montage pompe This part replaces 0306259. |
| 3 |
0305710 |
COVER |
| 4 |
0305587 |
SPRING, Check valve |
| 5 |
0305654 |
CHECK VALVE |
| 6 |
0305591 |
SPRING, Vernathem valve |
| 7 |
0308070 |
VALVE |
| 8 |
0305586 |
GASKET |
| 9 |
0305711 |
PLATE, Termostat housing |
| 10 |
0377276 |
VERNATHERM |
| 13 |
0377326 |
HOUSING THERMOSTAT |
| 14 |
0305589 |
GASKET, Housing to adaper |
| 16 |
0305640 |
PIN,Cotter,rod to shaft |
| 18 |
0306358 |
FLAT WASHER, Helm mounting |
| 19 |
0305483 |
ROD, Detent to shift lock |
| 21 |
0303887 |
WASHEER, Pin to swivel bracket |
| 22 |
0305598 |
BOLT, Carriage, detent |
| 25 |
0305618 |
SCREW |
| 27 |
0377275 |
PLATE & PIN, Detent adjust. |
| 28 |
0305639 |
DETENT, Adapter, gear shift |
| 29 |
0309956 |
GASKET, Adapter to h ead |
| 31 |
0343600 |
WASHER, Screw, pulley This part replaces 0305273. |
| 32 |
0329894 |
SCREW This part replaces 0302510. |
| 33 |
0306320 |
NUT |
| 34 |
0306799 |
L'WASHER,Bracket to hsg. |
| 37 |
0312837 |
GASKET |
| 39 |
0305152 |
GASKET, Inner to outer exhaust tube |
| 40 |
0305062 |
EXHAUST TUBE |
| 42 |
0305181 |
COUPLING, Flange |
| 43 |
0305145 |
GROMMET |
| 44 |
0307530 |
TUBE, Water, inlet |
| 45 |
0312328 |
TUBE, Water, outlet, standard |
| 46 |
0305536 |
CLAMP, Boot |
| 47 |
0381406 |
ADAPTER ASSEMBLY |
| 48 |
0310221 |
CORE PLUG |
| 49 |
0305314 |
RING,Exhaust tube seal |
| 50 |
0385496 |
EXHAUST HOUSING ASSY. |
| 51 |
0311522 |
GROMMET, Water tube |
| 52 |
0312275 |
PLUG |
| 53 |
0307522 |
SCREW, Cover plate |
| 54 |
0303862 |
COVER PLATE, Extension LONG SHAFT MODELS |
| 55 |
0304023 |
GASKET, Cover plate |
| 60 |
0304377 |
PIN, Shaft rod to lever |
| 61 |
0308017 |
SCREW, Bellcrank to shift lever |
| 62 |
0303721 |
CLIP, Shift rod |
| 63 |
0305342 |
LEVER, Shift rod |
| 64 |
0305537 |
ROD, Shift, upper |
| 66 |
0305538 |
WASHER, Inner |
| 67 |
0305674 |
ROD, Adjustment plate |
| 68 |
0306012 |
BOW WASHER |
| 70 |
0303887 |
WASHEER, Pin to swivel bracket |
| 71 |
0305831 |
SHIM |
| 72 |
0302473 |
BOW WASHER |
| 73 |
0305675 |
LINK, Shift rod |
| 74 |
0379240 |
SHAFT & ARM ASSEMBLY |
| 77 |
0305402 |
BOOT, Exhaust relief |
| 78 |
0305403 |
RETAINER, Relief spring |
| 79 |
0305397 |
SPRING, Exhaust relief |
| 80 |
0302863 |
SCREW, Base to adaptor |
| 82 |
0377972 |
MOUNT, Lower front |
