| Ref | Part Number | Description |
|---|
| 20 |
516006224 |
BRP Logo 20MM x 2MM This part replaces 219902677. |
| 600 |
515177249 |
DESS Switch |
| 610 |
278002963 |
Safety Nut (DESS Switch) This part replaces 278000508. |
| 620 |
515178284 |
DESS This part replaces 515177057. |
| 800 |
XXX |
Not Available As Spare Parts |
| 810 |
XXX |
Not Available As Spare Parts |
| 820 |
XXX |
Not Available As Spare Parts |
| 850 |
XXX |
Not Available As Spare Parts |
| 950 |
XXX |
Not Available As Spare Parts |
| 1000 |
XXX |
Not Available As Spare Parts |
| 1010 |
XXX |
Not Available As Spare Parts |
| 1050 |
XXX |
Not Available As Spare Parts |
| 1415 |
515176141 |
Cap |
| 2000 |
420664509 |
Temperature Sensor This part replaces 515177471. |
| 2200 |
515176366 |
Air Temperature Sensor |
| 2205 |
508000769 |
Seal |
| 2210 |
389804300 |
Push Nut |
| 2400 |
517304194 |
RH Headlamp Ass'y |
| 2400 |
517304195 |
LH Headlamp Ass'y |
| 2400a |
515176274 |
Halogen Bulb, 60/55 W, 12 V ( H4 ) |
| 2400b |
Not |
Available As Spare Part - Bulb Holder |
| 2400c |
219800280 |
Rubber Cap Protector This part replaces 515176499. |
| 2400d |
515176498 |
Cap |
| 2410 |
250000722 |
Torx Screw M6 X 20 This part replaces 250000128. |
| 2420 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250100113. |
| 3500 |
XXX |
Not Available As Spare Parts |
| 3510 |
XXX |
Not Available As Spare Parts |
| 3520 |
XXX |
Not Available As Spare Parts |
| 3600 |
515177289 |
Ground Wire |
| 4260 |
293450275 |
Insert This part replaces 415107300. |
| 4310 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 4312 |
250200041 |
Lock Washer Serrated M6 |
| 4520 |
515177272 |
Capacitor |
| 4524 |
515176607 |
Capacitor Support |
| 4530 |
250000462 |
Socket Head Screw M10 X 32 |
| 4535 |
250200026 |
Lock washer |
| 4540 |
516005515 |
CAPACITOR DECAL (ENGLISH) - Call your local BRP dealership |
| 4550 |
515177193 |
Cap |
| 9000 |
293750002 |
Tie Wrap 142 mm |
