| Ref | Part Number | Description |
|---|
| 1 |
5246131 |
Roiskeläppä |
| 2 |
36036 |
Vetoniitti |
| 3 |
21121 |
REFLECTOR (YELLOW) - Call your local BRP dealership |
| 4 |
5142828 |
Stöd, sida stänkskydd, höger |
| 5 |
5346740 |
Stöd, sido stänkskydd, höger |
| 5 |
5346741 |
Stöd, sido stänkskydd, vänster |
| 6 |
36097 |
Rivet Profix 4.0x13 Al musta(1=50pcs) - Call your local BRP dealership |
| 7 |
20037 |
Korilevy A4,3 |
| 8 |
5446916 |
Bracket |
| 9 |
21118 |
Heijastin, valkoinen |
| 10 |
40888 |
Wronic-ruuvi 4,2 x 19 |
| 12 |
A50121179000 |
TOOL BOX - Call your local BRP dealership This part replaces 708200041. |
| 13 |
572036400 |
COVER-BOX - Call your local BRP dealership |
| 14 |
549011291 |
Horn This part replaces 21003. |
| 15 |
414510200 |
REFLECTOR, AMBER - Call your local BRP dealership |
| 16 |
40063 |
Uraruuvi M5 x 12 |
