03- Mechanic - Steering Column
Parts (30)
| Ref | Part Number | Description |
|---|---|---|
| 70 | 207605554 | Hex. Flange Screw M10 X 55 |
| 80 | 233201466 | Flange Elastic Nut M10 |
| 120 | 709402421 | Steering Column |
| 130b | 709402725 | Steering Bushing |
| 150 | 709000089 | O-Ring |
| 160 | 709403085 | Steering Column |
| 170 | 709400790 | Bellows |
| 500 | 250000751 | Torx Screw M8 X 16 |
| 503 | 207662054 | Hex. Flange Screw M6 X 20 |
| 504 | 709402786 | Machined Support Reinforcement |
| 505 | 709402775 | Power Steering Support |
| 507 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip |
| 510 | 709402871 | Power Steering Ass'y |
| 520 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip |
| 530 | 709402782 | Machined Pitman Arm |
| 535 | 709402784 | Machined Pitman Arm |
| 540 | 709402783 | Link Rod |
| 550 | 705601974 | Ball Bearing |
| 560 | 705602003 | Spacer |
| 570 | 293300191 | O-Ring |
| 580 | 207605544 | Hex. Flange Screw M10 X 55 |
| 585 | 233201466 | Flange Elastic Nut M10 |
| 590 | 709403198 | Tie Rod |
| 600 | 706200281 | Hardened Washer |
| 610 | 709402236 | RH Knuckle Assembly |
| 620 | 709402233 | LH Knuckle Assembly |
| 630 | 250100089 | Hex. Elastic Hex. Nut M12 |
| 670 | 250001021 | Hex. Flange Screw M8 X 35 |
| 675 | 250001133 | Hex. Flange Screw M8 X 45 Scotch Grip |
| 680 | 232081417 | Hex. Nut M8 |
