| Ref | Part Number | Description |
|---|
| 2 |
20014 |
Spring washer |
| 3 |
420841201 |
Screw M8x70 |
| 4 |
207084544 |
Hex. Screw M8 X 45 This part replaces 420940631. |
| 5 |
420841561 |
Allen screw M8x45 |
| 6 |
420841841 |
SOCKET HEAD SCREW M8 X 65 - Call your local BRP dealership |
| 7 |
420640030 |
Stud M10 |
| 8 |
420945753 |
Lock washer |
| 9 |
232006414 |
Hex. Nut M10 This part replaces 33004. |
| 10 |
420840556 |
Stud M8 |
| 11 |
420860962 |
Cable grommet |
| 12 |
420899784 |
Loct 574/orange/50 |
| 13 |
293800060 |
Loctite 243, 10 ml This part replaces 420899785. |
| 14 |
Not |
Available As Spare Part - Instruction symbol decal - DOES NOT APPLY TO THIS MODEL |
| 15 |
Not |
Available As Spare Part - Reflector, bright - DOES NOT APPLY TO THIS MODEL |
| 16 |
Not |
Available As Spare Part - Reflector, yellow - DOES NOT APPLY TO THIS MODEL |
| 17 |
Not |
Available As Spare Part - Washer, hardened - DOES NOT APPLY TO THIS MODEL |
| 18 |
Not |
Available As Spare Part - Damper - DOES NOT APPLY TO THIS MODEL |
| 19 |
Not |
Available As Spare Part - Washer - DOES NOT APPLY TO THIS MODEL |
| 20 |
Not |
Available As Spare Part - Cup - DOES NOT APPLY TO THIS MODEL |
| 21 |
Not |
Available As Spare Part - Spring washer - DOES NOT APPLY TO THIS MODEL |
| 22 |
Not |
Available As Spare Part - Allen screw M8x25 - DOES NOT APPLY TO THIS MODEL |
