| Ref | Part Number | Description |
|---|
| 1 |
0203830 |
CAP, Propellar shaft |
| 2 |
0310207 |
DRIVESHAFT |
| 2 |
0310352 |
DRIVESHAFT |
| 3 |
0317372 |
GROMMET, Wate tube, lower |
| 4 |
0310344 |
HOUSING, Impeller |
| 5 |
0302963 |
SCREW |
| 6 |
0203132 |
PLATE, Pump |
| 7 |
0277181 |
IMPELLER & PIN ASSY |
| 9 |
0385186 |
GEARCASE & EXH. COV. ASSY. |
| 16 |
0310206 |
GEAR, Dreivshaft pinion |
| 17 |
0381042 |
PROPELLER SHAFT ASSEMBLY |
| 20 |
0382586 |
GEARCASE HEAD ASSY |
| 25 |
0302804 |
COTTER IN |
| 26 |
0317484 |
DRIVE PIN |
| 27 |
0379466 |
HUB, Propeller clutch |
| 28 |
0310331 |
RING, Clutch |
| 29 |
0300619 |
BUSHING, Clutch |
| 30 |
0315858 |
PROPELLER - 8 INCH X 5-1/2 INCH |
| 31 |
0300573 |
WASHER |
| 32 |
0203829 |
NUT, Propeller |
| 33 |
0308707 |
SCREW |
| 35 |
0909533 |
SCREW, Pressure relief valve cover This part replaces 0309646. |
| 36 |
0310355 |
EXRENSION,Gearcase 5" LONGER PARTS |
| 37 |
0315604 |
WATER TUBE |
| 38 |
0310744 |
PILOT RING 5 INCH LONGER PARTS |
| 0132691 |
0132691 |
COMPRESSION NUT |
| 0306344 |
0306344 |
BALL SLEEVE |
| 0384008 |
0384008 |
EXR. KIT ASSY.-5"LONGER 5" LONGER PARTS |
| 0385187 |
0385187 |
GEARCASE ASSEMBLY |
