| Ref | Part Number | Description |
|---|
| 1 |
0122441 |
STEERING SHAFT, Twin drive |
| 1 |
0122442 |
STEERING SHAFT, Single drive |
| 2 |
0122454 |
RETAINER, Drive unit |
| 3 |
0122443 |
RETAINING RING |
| 4 |
0122444 |
THRUST WASHER, Shaft |
| 5 |
0122445 |
WASHER, Shaft |
| 7 |
0122446 |
SUPPORT, Shaft |
| 8 |
0304583 |
SCREW, Nameplate |
| 9 |
0122452 |
NAMEPLATE |
| 10 |
0300646 |
VIS, ancrage |
| 12 |
0306358 |
FLAT WASHER, Helm mounting |
| 13 |
0311273 |
BEARING, Helm |
| 14 |
0311274 |
BRAKE |
| 15 |
0122451 |
TRIM RING |
| 16 |
0122449 |
WASHER, Brake |
| 17 |
0306890 |
SCREW, Helm mounting |
| 18 |
0122560 |
FLAT WASHER, Helm mtg |
| 19 |
0122450 |
BRAKE, Screw |
| 20 |
0904880 |
LOCKNUT, Steering shaft |
| 21 |
0304671 |
LOCKWASHER, Coupler to flywheel |
| 23 |
0122460 |
BEARING, Pinion |
| 0122453 |
0122453 |
SCREW, Cable drive housing, twin drive |
| 0172608 |
0172608 |
ROTAMANTIC 1 HELM ASSY., Twin drive |
| 0172609 |
0172609 |
ROTAMATIC 1 HELM ASSY., Single drive |
