| Ref | Part Number | Description |
|---|
| 32 |
278000998 |
Female Terminal |
| 33 |
278000999 |
Wire Seal |
| 34 |
409010100 |
Female Terminal |
| 36 |
409010400 |
Female Terminal Housing, 1 Circuit |
| 41 |
515175232 |
Male Terminal |
| 44 |
515175231 |
Female Terminal |
| 46 |
515175282 |
Female Terminal |
| 54 |
515175495 |
Female Housing, 3 Circuits |
| 61 |
409012900 |
Male Terminal |
| 62 |
278001014 |
Female Terminal |
| 64 |
710000568 |
Housing |
| 68 |
409209500 |
Female Housing, 2 Circuits |
| 69 |
409209600 |
Female Housing, 3 Circuits |
| 73 |
278001013 |
Wire Seal |
| 99 |
278000992 |
Open Barrel |
| 112 |
278000632 |
Female Terminal |
| 138 |
293000052 |
Sealing Cap |
| 188 |
409902000 |
Tubing 12 mm |
| 191 |
410917200 |
Fuse, 30 Amperes |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 203 |
278001113 |
Male Connector, 2 Circuits |
| 206 |
409004200 |
Female Terminal |
| 223 |
515175320 |
FEMALE TERMINAL - Call your local BRP dealership |
| 225 |
409202700 |
FEMALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 248 |
409004000 |
Fuse Holder |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 304 |
515175504 |
Ring Terminal |
| 317 |
278001473 |
Female Terminal Housing, 4 Circuits |
| 320 |
515175567 |
Female Terminal |
| 351 |
278001474 |
Female Lock, 4 Circuits |
| 354 |
515175654 |
Male Terminal Housing, 2 Circuits |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 363 |
515175670 |
Female Terminal Housing, 2 Circuits |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 368 |
515175675 |
Female Lock, 2 Circuits |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 383 |
515175719 |
FEMALE TERMINAL HOUSING, 11 CIRCUITS - Call your local BRP dealership |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 415 |
515175806 |
Female Terminal |
| 417 |
515175819 |
Female Terminal Housing, 8 Circuits |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 481 |
415128500 |
Female Terminal Housing, 2 Circuits |
| 498 |
710000399 |
Female Housing |
| 645 |
515176164 |
Male Terminal |
| 663 |
515176774 |
Relay, 30 AMP This part replaces 710000739. |
| 664 |
515176775 |
Relay, 50 AMP This part replaces 710000740. |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 667 |
710000743 |
Little Fuse, 7.5 Amperes |
| 668 |
710000744 |
Little Fuse, 10 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 670 |
710000746 |
Little Fuse, 20 Amperes |
| 674 |
710001026 |
Fuse Cover This part replaces 710000659. |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 695 |
515176283 |
KEYING PIN - Call your local BRP dealership |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 764 |
710000992 |
Clip |
| 827 |
710001119 |
Female Terminal |
| 831 |
710001131 |
Female Terminal |
| 930 |
515176621 |
Wire Seal |
| 937 |
515176636 |
DIODE 6 AMP. - Call your local BRP dealership |
| 1001 |
515176521 |
FUSE DECAL - Call your local BRP dealership |
