09- Luggage Rack _36M1525
Parts (12)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 233251494 | Elastic Flange Nut M5 |
| 2 | 250000297 | Truss Head Torx Screw K50 X 20 |
| 3 | 250000446 | Torx Screw M6 X 20, Scotch Grip |
| 4 | 293150067 | Rivet |
| 5 | XXX | Not Available As Spare Parts |
| 6 | 511000568 | Deep Black Trunk Cover |
| 7 | 511000528 | Bracket |
| 8 | XXX | Not Available As Spare Parts |
| 9 | XXX | Not Available As Spare Parts |
| 10 | 511000757 | Trunk |
| 11 | 511000822 | Threaded Insert |
| 12 | 860201806 | Luggage Rack Base With Hardware This part replaces 511000779. |
