| Ref | Part Number | Description |
|---|
| 3 |
0338778 |
RETAINING RING |
| 7 |
0341280 |
SEAL |
| 27 |
0341281 |
SEAL |
| 29 |
0305123 |
O RING |
| 53 |
0435933 |
GEARSET ASSY. |
| 62 |
0329865 |
SHIFT ROD |
| 63 |
5007672 |
DRIVESHAFT Assembly, Upper This part replaces 0435766. |
| 66 |
0331188 |
O-Ring |
| 70 |
0331998 |
SCREW, Gearcase to housing |
| 72 |
0331999 |
SCREW, Gearcase housing |
| 73 |
0331353 |
Seal, Impeller Housing Plate. |
| 80 |
0330263 |
SCREW, Mounting, 3/8 in. X 3.50 in. |
| 81 |
0392160 |
ANODE KIT |
| 89 |
0338743 |
TRIM TAB |
| 91 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 95 |
PROPELLER |
Ref: 96 0313926 *Propeller Hub Sleeve 0313926 |
| 98 |
5006373 |
GEARCASE SEAL KIT This part replaces 0437753. |
| 99 |
5001595 |
Water Pump Repair Kit This part replaces 0435929. |
| 0438044 |
0438044 |
GEARCASE ASSY., Complete |
