| Ref | Part Number | Description |
|---|
| 1 |
0987219 |
CABLE ASSY. MOTOR |
| 2 |
0915685 |
BOOT, Ring terminal, actuator |
| 3 |
3853478 |
SEAL, Temperature switch This part replaces 0915237. |
| 5 |
0987424 |
CONNECTOR, Interface |
| 6 |
0915673 |
TERMINAL, Interface |
| 7 |
0987425 |
CONNECTOR, Governor |
| 8 |
0915674 |
TERMINAL, Governor, #18 GA |
| 9 |
3853533 |
TERMINAL This part replaces 0915675. |
| 10 |
0513201 |
CONNECTOR |
| 12 |
0513202 |
CONNECTOR |
| 17 |
3854114 |
CONNECTOR HSG., Engine coolant This part replaces 0987426. |
| 18 |
0915677 |
TERMINAL, Coolant temperature |
| 19 |
0987427 |
RECEPTACLE, Coolant level |
| 20 |
0915678 |
TERMINAL, Actuator potometer |
| 25 |
3853480 |
HOUSING, Knock sensor This part replaces 0915239. |
| 26 |
3853479 |
TERMINAL, Temperature switch This part replaces 0915238. |
| 27 |
0987428 |
RECEPTACLE, Actuator potometer |
| 28 |
0915678 |
TERMINAL, Actuator potometer |
| 29 |
3854115 |
CONNECTOR HSG., MAP sensor This part replaces 0987429. |
| 30 |
3853534 |
TERMINAL, Ignition module This part replaces 0915679. |
| 36 |
0915681 |
TERMINAL, Ring |
| 37 |
0915682 |
TERMINAL, Ring |
| 40 |
3852527 |
RING TERMINAL This part replaces 0911523. |
| 42 |
0915683 |
TERMINAL , Ring, starter |
| 44 |
0914575 |
COVER, Oil switch terminal |
| 46 |
0916040 |
SEAL, Boost connector |
| 47 |
3853699 |
RETAINER This part replaces 0916145. |
| 48 |
3853702 |
RETAINER, MAP sensor This part replaces 0916149. |
| 49 |
0916046 |
HARNESS, Ground strap |
| 50 |
3852620 |
TIE STRAP, Oil lines This part replaces 0915686. |
| 51 |
0915687 |
PLUG, Intercooler drain |
| 55 |
0915399 |
WASHER, Bolt, water pump |
| 56 |
0915550 |
PLUG SCREW, Expansion tank top |
| 58 |
3852487 |
BOOT, Battery cable This part replaces 0910111. |
| 59 |
0916028 |
TIE STRAP, Hose to starter |
| 60 |
3852825 |
RETAINER, Engine cable This part replaces 0913770. |
| 61 |
0333672 |
SCREW , Cable retainer |
| 62 |
0915688 |
TIE STRAP, Connector to bracket |
| 64 |
0915667 |
WASHER, Interface unit |
| 65 |
0915668 |
SCREW, Tapping |
| 66 |
0915470 |
WASHER, Clamp to heatshield |
| 67 |
0915654 |
CAP NUT, E-box base plate |
| 68 |
0512741 |
DISPOSITIF DE RETENUE, conn. de l'interrupteur thermostatique |
| 69 |
0512742 |
DISPOSITIF DE RETENUE, connecteur |
| 72 |
3852736 |
SCREW, Alternator ground This part replaces 0913580. |
| 73 |
0311375 |
NUT |
| 80 |
0915689 |
SCREW, Starter connection, small |
| 81 |
0915690 |
WASHER, Main ground terminal |
| 82 |
0915691 |
NUT, Main ground terminal |
| 83 |
0915690 |
WASHER, Main ground terminal |
| 84 |
0915691 |
NUT, Main ground terminal |
| 85 |
0915922 |
WASHER, Actuator connection |
| 86 |
0915923 |
NUT, Actuator connection |
| 87 |
0915692 |
WASHER, Fuel pump, + terminal |
| 88 |
0915693 |
NUT, Fuel pump, + terminal |
| 89 |
0915922 |
WASHER, Actuator connection |
| 90 |
0915923 |
NUT, Actuator connection |
| 91 |
0310947 |
CLAMP |
| 92 |
0915646 |
BOLT, Clamp |
| 93 |
0310947 |
CLAMP |
| 94 |
3853786 |
CLAMP INSTRUMENT CABLE This part replaces 0980577. |
| 95 |
0915921 |
PLATE, Harness tie strap |
