Light Frame
Parts (23)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 619590531 | Light Beam [left] [black] |
| 2 | 619590532 | Light Beam [right] [black] |
| 4 | 619590530 | Joint |
| 6 | 619590479 | Light Bar |
| 7 | 619590445 | Lock plate L |
| 8 | 619590444 | Lock plate R |
| 9 | 619590438 | Clamping plate |
| 10 | 619590436 | Light bracket [left] [black] |
| 11 | 619590437 | Light bracket [right] [black] |
| 12 | 619590440 | Lampholder |
| 17 | 619590476 | Reflector |
| 18 | 269700109 | Latch Ass'y This part replaces 619590465. |
| 19 | 619590467 | Soft Pad |
| 20 | 619590498 | Torx Screw [Black] M6 x 40 |
| 23 | 619590502 | Torx Screw M6 x 30 |
| 24 | 619590515 | Elastic Locking Nut M6 |
| 25 | 619590494 | Torx Screw [Black] M5 x 12 |
| 25 | 619590534 | Torx Screw [Panhead] TP 5 x 12 |
| 26 | 619590495 | Torx Screw M6 x 8 |
| 27 | 619590535 | Torx Screw RX TP 4,0 x 12 [Black] |
| 28 | 619590501 | Torx Screw RX TP 5,0 x 12 [Black] |
| 29 | 619590500 | Torx Screw [Black] M8 x 35 |
| 30 | 619590484 | Bushing |
