| Ref | Part Number | Description |
|---|
| 5 |
0322776 |
ORIFICE 150 only |
| 6 |
0330131 |
CLAMP, Fuel filter |
| 7 |
0319682 |
VIS, capteur vers plaque |
| 8 |
0392376 |
FLOAT CHAMBER ASSY. This part replaces 0393784. |
| 14 |
0330056 |
ROLLER, Cam follower |
| 15 |
0321449 |
ORIFICE PLUG 175 ONLY, No. 60c |
| 15 |
0321559 |
ORIFICE PLUG |
| 15 |
0329911 |
ORIFICE PLUG 159 ONLY,No.54c |
| 16 |
0338884 |
GASKET, Float bowl This part replaces 0323784. |
| 18 |
0383437 |
FLOAT ASSEMBLY |
| 22 |
0336842 |
CLIP, SPRING This part replaces 0603145. |
| 23 |
0308776 |
O-RING |
| 24 |
0327707 |
GASKET, Air silencer |
| 0393773 |
0393773 |
CARB ASSY., Lower 150 only |
| 0393774 |
0393774 |
CARB ASSY., Middle 150 only |
| 0393779 |
0393779 |
CARB ASSY., Lower 175, 185 |
| 0393780 |
0393780 |
CARB ASSY., Middle 175, 185 |
| 0393781 |
0393781 |
CARB ASSY., Lower 235 only |
| 0393782 |
0393782 |
CARB ASSY., Middle 235 only |
