| Ref | Part Number | Description |
|---|
| 1 |
0392196 |
GEARCASE & BRG ASSY |
| 5 |
0387066 |
BEARING HOUSING & PIN |
| 9 |
0322636 |
DETENT, Shifter |
| 10 |
0320120 |
LEVER, Shifter |
| 13 |
3854249 |
BEARING, Driveshaft, lower This part replaces 0386768. |
| 14 |
0320172 |
SHAFT, Shifter |
| 18 |
0319895 |
SHIFT,Clutch dog |
| 19 |
0320115 |
THRUST WASHER |
| 20 |
0386719 |
THRUST BEARING, Rev gear |
| 23 |
0386659 |
PROPELLER SHAFT ASSY |
| 24 |
0320113 |
GEAR, Reverse |
| 25 |
0320304 |
RETAINER PLATE, Brg hsg |
| 26 |
0320309 |
RETAINER RING |
| 27 |
0320303 |
O RING, Housing |
| 28 |
0386920 |
BEARING HOUSING ASSY |
| 33 |
0317178 |
O RING |
| 34 |
0307151 |
SCREW |
| 36 |
0320165 |
SHIM, .002" |
| 36 |
0320166 |
SHIM, . 003" |
| 36 |
0320167 |
SHIM , . 004" |
| 36 |
0320168 |
SHIM, . 005" |
| 36 |
0320169 |
SHIM , . 006" |
| 36 |
0320170 |
SHIM , . 007" |
| 38 |
0389965 |
GEAR AND PINION ASSY, Forward |
| 40 |
0320127 |
SHIFT ROD, Standard |
| 42 |
0387067 |
BEARING HOUSING & SEAL ASSY |
| 48 |
0385175 |
CONE & GOLLER ASSY. |
| 50 |
0324980 |
LINDER, Impeller housing |
| 51 |
0321940 |
PLATE |
| 56 |
0432955 |
WATER PUMP REPAIR KIT (includes impeller housing) This part replaces 0391049. |
| 58 |
0319292 |
SCREW, Clamp |
| 60 |
0323950 |
KEY, Drive shaft to impeller |
| 62 |
0320040 |
SCREW, Trim tab std. models |
| 63 |
0031502 |
COTTER PIN,Propeller nut |
| 64 |
0338742 |
COMPENSATEUR DE DÉRIVE This part replaces 0327810. |
| 66 |
0307708 |
RONDELLE GROWER |
| 70 |
0306314 |
L'WASHER,Scr,long |
| 71 |
0313697 |
SCR,Grc to hsg.long |
| 72 |
0327482 |
BLOCK, Gearcase |
| 73 |
0303886 |
LOCKWASHER |
| 74 |
0322000 |
SCREW, Starter to crankcase |
| 75 |
0176423 |
PROPELLER, 11 1/4 x 19 - Aluminum This part replaces 0386908. |
| 75 |
0386786 |
PROPELLER, 11-3/4 X 15 |
| 75 |
0386841 |
PROPELLER |
| 75 |
0386907 |
PROPELLER 13 X 11 |
| 75 |
0386909 |
PROPELLER, 12 - 1/2 x 13 |
| 75 |
0390849 |
PROPELLER, 11-1/2 x 13-SST |
| 75 |
0390850 |
PROPELLER, 12 1/4 x 15 - SST |
| 75 |
0390851 |
PROPELLER, 11 3/4 x 17 - SST |
| 75 |
0390852 |
PROPELLER, 11 1/4 x 19 - SST |
| 75 |
0391014 |
PROPELLER 11-1/4 X 21 |
| 75 |
0391015 |
PROPELLER 11-1/4 X 21 - SST |
| 78 |
0389145 |
CHROME CUP & PLATE KIT |
| 79 |
0391634 |
WATER PUMP REAIR KIT, ( includes imeller hsg) |
| 79 |
0396726 |
WATER PUMP REPAIR KIT This part replaces 0390769. |
| 0307853 |
0307853 |
O RING |
| 0393137 |
0396731 |
GEARCASE ASSY. This part replaces 0393137. |
