| Ref | Part Number | Description |
|---|
| 1 |
0583285 |
PLAT & SLEEVE ASSY. |
| 7 |
0303212 |
VIS, collier & capot |
| 9 |
0511460 |
VIS, dispositif de retenue |
| 10 |
0511458 |
COLLIER, fils |
| 11 |
0511459 |
CACHE, fils |
| 12 |
0584333 |
CHARGE COIL & LAM. ASSY. |
| 15 |
0320504 |
SCREW, Bracket to carburetor |
| 16 |
0584341 |
STATOR ASSEMBLY |
| 20 |
0511601 |
SLEEVE, Leads |
| 21 |
0584489 |
IGNITION MODULE This part replaces 0584329. |
| 33 |
0326111 |
NUT |
| 34 |
0584216 |
MOTOR CABLE ASSY. |
| 49 |
0512742 |
DISPOSITIF DE RETENUE, connecteur |
| 50 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 56 |
0332070 |
SCREW, Retaining plate This part replaces 0326875. |
| 57 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 58 |
0332790 |
RETAINER |
| 60 |
0332063 |
PLATE, Support |
| 61 |
0330184 |
VIS, montage pompe This part replaces 0306259. |
| 62 |
0583696 |
FLYWHEEL ASSEMBLY |
| 63 |
0329182 |
VIS, borne |
| 64 |
0583740 |
COIL Assy |
| 65 |
0581778 |
REDRESSEUR |
| 68 |
0306644 |
VIS, capteur de papillon |
| 69 |
0512741 |
DISPOSITIF DE RETENUE, conn. de l'interrupteur thermostatique |
| 73 |
0334189 |
BRACKET |
| 74 |
0335020 |
SCREW, Bracket to block |
| 76 |
0306644 |
VIS, capteur de papillon |
| 78 |
0333757 |
COVER |
| 84 |
0583955 |
CABLE AY |
| 87 |
0583956 |
CABLE AY |
| 96 |
0583957 |
CABLE AY |
| 0583954 |
0583954 |
RELAY & CABLE AY. |
