| Ref | Part Number | Description |
|---|
| 1 |
204940002 |
WATER TANK - Call your local BRP dealership |
| 2 |
293830044 |
PROTECTOR PAD - Call your local BRP dealership |
| 3 |
204940003 |
WATER TANK STRAP - Call your local BRP dealership |
| 4 |
275500252 |
TANK BRACKET - Call your local BRP dealership |
| 5 |
207183060 |
Hex. Screw M8 X 30 |
| 6 |
293800060 |
Loctite 243, 10 ml |
| 7 |
234181601 |
Lock Washer 8 mm, Stainless |
| 8 |
234082600 |
Flat Washer 8 mm, Stainless |
| 9 |
207185560 |
HEX. SCREW M8 X 55 - Call your local BRP dealership |
| 10 |
232581600 |
Hex. Elastic Nut M8 |
| 11 |
204940010 |
FRESH WATER HOSE, METER - Call your local BRP dealership |
| 12 |
293650069 |
NORMA CLAMP - Call your local BRP dealership |
| 13 |
204940005 |
PVC Hose, Meter |
| 14 |
293650074 |
Norma Clamp |
| 15 |
204940015 |
PVC Hose 16 Mm , Meter |
| 16 |
293650172 |
Tridon Gear Clamp |
| 17 |
204940041 |
VENT NECK-FILLER - Call your local BRP dealership |
| 18 |
208643060 |
Phillips Screw M4 X 30 |
| 19 |
293800060 |
Loctite 243, 10 ml |
| 20 |
234042600 |
Flat Washer 4 mm, Stainless |
| 21 |
232541600 |
Elastic Stop Nut M4 |
| 22 |
204940008 |
FRESH WATER HOSE, METER - Call your local BRP dealership |
| 23 |
293650172 |
Tridon Gear Clamp |
| 24 |
204940011 |
T-Fitting |
| 25 |
204940009 |
ELBOW FITTING 90 - Call your local BRP dealership |
| 26 |
204940007 |
FRESH WATER FILTER - Call your local BRP dealership |
| 27 |
204940019 |
MALE FITTING 1/2? - Call your local BRP dealership |
| 28 |
219704455 |
Was 293800018 Loctite 592, 50 ml |
| 29 |
204940029 |
Bag, Hose/Shower |
| 30 |
204940018 |
FRESH WATER SHOWER - Call your local BRP dealership |
| 31 |
208443060 |
Phillips Screw M4 X 30 |
| 32 |
234042600 |
Flat Washer 4 mm, Stainless |
| 33 |
232541600 |
Elastic Stop Nut M4 |
| 34 |
204940011 |
T-Fitting |
| 35 |
204940031 |
NYLON FITTING 1/2, 90 - Call your local BRP dealership |
| 36 |
204940030 |
NYLON FITTING 1/2? - Call your local BRP dealership |
| 37 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 38 |
204940017 |
Sink Faucet |
| 39 |
204940032 |
Nylon Fitting 1/2” X 3/4” |
| 40 |
204940010 |
FRESH WATER HOSE, METER - Call your local BRP dealership |
| 41 |
204940051 |
Washdown Cup |
| 42 |
204940020 |
WASHDOWN FAUCET - Call your local BRP dealership |
| 43 |
208441660 |
PHILLIPS SCREW M4 X 16 - Call your local BRP dealership |
| 44 |
234042600 |
Flat Washer 4 mm, Stainless |
| 45 |
232541600 |
Elastic Stop Nut M4 |
| 46 |
209642560 |
PHILLIPS SCREW M4.2 X 25 - Call your local BRP dealership |
| 47 |
204940025 |
Fountain Nozzle |
| 48 |
204940027 |
Extension Tube |
| 49 |
204940024 |
DIVERTER VALVE - Call your local BRP dealership |
| 50 |
204940023 |
Elbow Fitting 3/4”, 90° |
| 51 |
293650074 |
Norma Clamp |
| 52 |
204940012 |
Hose 1-1/8”, Meter |
| 53 |
204940036 |
Water Hose |
| 54 |
204940010 |
FRESH WATER HOSE, METER - Call your local BRP dealership |
| 55 |
204130176 |
SLIT CONDUIT 1 - Call your local BRP dealership This part replaces 204560132. |
| 56 |
293750002 |
Tie Wrap 142 mm |
| 57 |
293650016 |
Tridon Clamp |
| 58 |
204940035 |
Thru Hull Fitting |
| 60 |
296000309 |
Silicone Sealant 51388, 300 ml |
| 61 |
291001206 |
BILGEFLEX HOSE 3/4, BLACK, METER - Call your local BRP dealership |
