| Ref | Part Number | Description |
|---|
| 1 |
0203363 |
RETAINER This part replaces 3852034. |
| 2 |
3854152 |
VALVE, Pressure |
| 3 |
3852462 |
FITTING, Cover, return line |
| 4 |
3853557 |
SCREW, Brace to alterntr bracket |
| 5 |
0909988 |
BUSHING, Tilt & trim cable This part replaces 3852481. |
| 6 |
3852017 |
ADAPTER, Fuel line |
| 7 |
3853642 |
O-RING, Retainer, fuel pump |
| 8 |
3853572 |
RETAINER, Fuel pump to cover |
| 9 |
3853573 |
BRACKET, Fuel pump grommet |
| 10 |
3857728 |
GASKET, Cover, reservoir |
| 11 |
3853575 |
FLOAT |
| 12 |
3853576 |
SEAT, Float needle |
| 13 |
3853577 |
GASKET, Float needle seat |
| 14 |
0915883 |
NEEDLE, Float This part replaces 3853578. |
| 15 |
3853579 |
CLIP, Needle to float |
| 16 |
3853597 |
ELBOW, Vent, reservoir to intake |
| 17 |
0174177 |
ELBOW KIT This part replaces 3852480. |
| 18 |
3853606 |
SCREW, Cover to reservoir |
| 20 |
3857650 |
FUEL PUMP, High pressure |
| 21 |
3854149 |
RESERVOIR ASSY. |
| 23 |
3853326 |
SCREW, Bracket to engine |
| 24 |
3856438 |
BRACKET, Fuel filter & pump |
| 25 |
3852029 |
SENDER, Water temperature |
| 26 |
3854405 |
COVER, Reservoir |
| 28 |
3852108 |
CLAMP, Distributor |
| 29 |
3857662 |
GASKET SET, Intake manifold |
| 30 |
3852013 |
ELBOW, Filter inlet |
| 33 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet This part replaces 3852158. |
| 34 |
3853620 |
SCREW, Circuit breaker |
| 35 |
0909988 |
BUSHING, Tilt & trim cable This part replaces 3852481. |
| 36 |
3856270 |
INTAKE MANIFOLD |
| 37 |
0312780 |
GASKET, Dist. to manifold This part replaces 3852109. |
| 38 |
3850861 |
COVER & FUEL FILTER ASSY |
| 39 |
5012363 |
Filter Ay This part replaces 0502906. |
| 40 |
3853494 |
FITTING |
| 41 |
3850820 |
O-RING |
| 42 |
3853311 |
BRACKET, Lift |
| 44 |
3854163 |
CIRCUIT BREAKER, 20A Fuel pump |
| 45 |
3855935 |
BOLT, Manifold to head |
| 46 |
3852476 |
CAP, Manifold |
| 47 |
3860811 |
Bracket This part replaces 3857411. |
| 48 |
3853310 |
BRACKET, Fuel filter |
| 50 |
3850278 |
LINE, TBI to reservoir |
| 51 |
3856534 |
LINE, Fuel pump to reservoir |
| 52 |
3852019 |
TRUNNION, S.A.E. Cable |
| 53 |
3850266 |
ANCHOR BLOCK |
| 54 |
0303459 |
ECREW,Exhaust cover,1-1/2"long This part replaces 3852048. |
| 55 |
3853326 |
SCREW, Bracket to engine |
| 57 |
3850689 |
HOSE, Vent reservoir to intake |
| 58 |
3850039 |
ADAPTER, Intake manifold |
| 59 |
3855290 |
BRACKET, Fuel line |
| 60 |
0511514 |
CLAMP, Cable This part replaces 3852231. |
| 62 |
3855190 |
O-RING, Regulator |
| 63 |
3850405 |
CAP, Distributor plug |
| 67 |
3853493 |
FITTING, Filter outlet to pump |
| 69 |
3850355 |
GASKET, Throttle body |
| 70 |
HOSE, |
MAP sensor |
| 71 |
3850423 |
O-RING, 5/16 in. |
| 72 |
3850424 |
O-RING, 3/8 in. |
| 73 |
3853494 |
FITTING |
| 74 |
3850820 |
O-RING |
| 75 |
0912627 |
CLAMP This part replaces 3852602. |
| 76 |
3850277 |
LINE, Pump to TBI |
| 77 |
3852008 |
SCREW, Adapter |
| 79 |
3853399 |
SCREW, Brace to alternator |
| 80 |
3856129 |
BOLT, Intake manifold, short |
| 81 |
3854763 |
BRACKET, Reservoir |
| 82 |
3853794 |
CLAMP, Anti-siphon hose |
| 83 |
3850396 |
SENSOR, Manifold air pressure |
| 84 |
3852335 |
HOSE, Tee to high rise |
| 85 |
3850374 |
SEAL KIT, Fuel reservoir |
| 87 |
3860812 |
Stud This part replaces 3852160. |
| 88 |
3850272 |
BRACKET, Knock module |
| 89 |
3851990 |
BRACKET, PCM & knock module |
| 90 |
3858733 |
Module & Decal Ay This part replaces 3857926. |
| 90 |
3858734 |
Module & Decal Ay This part replaces 3857775. |
| 90 |
3858782 |
Module & Decal Ay This part replaces 3857925. |
| 91 |
3858847 |
Water Pump Ay This part replaces 3855778. |
| 93 |
3850356 |
MODULE, Knock |
| 95 |
3852075 |
PLUG, Intake manifold |
| 96 |
3853558 |
BOLT, Bracket to head |
| 97 |
3856449 |
FITTING, Reservoir |
