| Ref | Part Number | Description |
|---|
| 1 |
3854135 |
CABLE, Engine |
| 2 |
3852527 |
RING TERMINAL |
| 5 |
3853675 |
TERMINAL, E-coil |
| 6 |
3853705 |
CONNECTOR HOUSING, E-coil |
| 7 |
3853534 |
TERMINAL, Ignition module |
| 8 |
3853676 |
TERMINAL |
| 9 |
3853565 |
CONNECTOR |
| 10 |
3853677 |
RETAINER, Ignition module |
| 11 |
3853678 |
CONNECTOR HSG., Ignition module |
| 13 |
3854192 |
CONNECTOR, Relay |
| 18 |
3853679 |
ISOLATOR, Relay mounting |
| 19 |
3852260 |
CONNECTOR |
| 20 |
3853681 |
BOOT |
| 21 |
3853682 |
TERMINAL, Self test |
| 22 |
3853683 |
CONNECTOR HSG., Test output |
| 23 |
3853533 |
TERMINAL |
| 24 |
3853684 |
TERMINAL |
| 25 |
3853685 |
RETAINER, ECA module |
| 27 |
0328074 |
CACHE, cosse prise This part replaces 3852181. |
| 29 |
3853689 |
RETAINER, By-pass solenoid |
| 30 |
3853690 |
CONNECTOR HOUSING, Bypass solenoid |
| 31 |
3853479 |
TERMINAL, Temperature switch |
| 32 |
3853478 |
SEAL, Temperature switch |
| 33 |
3853480 |
HOUSING, Knock sensor |
| 35 |
0914745 |
COVER This part replaces 3853320. |
| 36 |
3853691 |
TERMINAL |
| 37 |
3853692 |
TERMINAL, Distributor |
| 38 |
3853693 |
RETAINER, Distributor |
| 39 |
3853694 |
CONNECTOR HSG., Distributor |
| 40 |
3853695 |
TERMINAL, Fuel injector |
| 41 |
3853696 |
RETAINER, Fuel injector |
| 42 |
3853697 |
CONNECTOR HSG., Fuel injector |
| 43 |
3853698 |
TERMINAL |
| 44 |
3853699 |
RETAINER |
| 45 |
3853995 |
CONNECTOR, Knock sensor |
| 46 |
3853700 |
RETAINER, Throttle position |
| 47 |
3853701 |
CONNECTOR HOUSING, Throttle position |
| 48 |
3853702 |
RETAINER, MAP sensor |
| 49 |
3854115 |
CONNECTOR HSG., MAP sensor |
| 51 |
3853703 |
CONNECTOR HSG., Air charge |
| 52 |
3854114 |
CONNECTOR HSG., Engine coolant |
| 53 |
3853704 |
CONNECTOR HSG., Test input |
| 55 |
3853706 |
BOOT, ECA Module |
| 56 |
3853707 |
TERMINAL, E-coil |
| 61 |
3850985 |
FUSE |
| 62 |
3852499 |
RETAINER, Fuse |
| 63 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet This part replaces 3852158. |
| 65 |
3853688 |
CONNECTOR HSG., ECA |
| 66 |
3853687 |
COVER, Connector housing |
| 67 |
0987704 |
CIRCUIT BREAKER, 50 Amp This part replaces 3854283. |
| 67 |
3854186 |
CIRCUIT BREAKER, 60 Amp |
| 67 |
3854282 |
BREAKER, Fuel pump |
| 68 |
3854205 |
CABLE, Solenoid to solenoid |
| 69 |
3853752 |
TIE STRAP, ECA Module |
| 70 |
3853786 |
CLAMP INSTRUMENT CABLE |
| 71 |
3853611 |
COVER, Self test output |
| 72 |
3854189 |
COVER & SEAL, ECA module |
| 74 |
3853643 |
JUMPER, Timing test lead |
| 75 |
3854185 |
LEAD, Solenoid to breaker |
| 77 |
0512902 |
RING TERMINAL This part replaces 3852245. |
| 78 |
3854889 |
MODULE, ECA, 5.0 Litre This part replaces 3854228. |
| 78 |
3854890 |
MODULE, ECA, 5.8 Litre This part replaces 3854229. |
| 81 |
3854138 |
RELAY, Engine control |
| 82 |
3852825 |
RETAINER, Engine cable |
| 83 |
0328731 |
VIS, câble de verrouillage This part replaces 3852194. |
| 86 |
0335200 |
VIS, capteur position de vilebrequin vers support This part replaces 3852212. |
| 87 |
0341013 |
SCREW, Cover This part replaces 3852454. |
| 88 |
3853620 |
SCREW, Circuit breaker |
| 89 |
0586842 |
SOLENOID This part replaces 3853839. |
| 90 |
3853617 |
SPACER, Bushing |
| 91 |
0315770 |
WASHER, Electrical bracket This part replaces 3852136. |
| 96 |
0512742 |
DISPOSITIF DE RETENUE, connecteur This part replaces 3852237. |
| 97 |
0512743 |
DISPOSITIF DE RETENUE This part replaces 3852238. |
| 98 |
3854216 |
MODULE ASSY., Knock |
| 101 |
3852487 |
BOOT, Battery cable |
| 102 |
3853734 |
CLIP, Connector |
| 103 |
3852411 |
CONNECTOR & PLUG ASSY. |
