07- FURNITURE - Stern Bench
Parts (48)
| Ref | Part Number | Description |
|---|---|---|
| 200 | 295101046 | LH Panel Seat Switch Kit |
| 250 | 295101047 | RH Panel Seat Switch Kit |
| 500a1 | 295101127 | Seat Support Service Kit |
| 500a10a | 233181600 | Hex. Flange Nut M8 |
| 500a11 | 250200130 | Flat Washer 8 mm |
| 500a12 | 219905883 | Seat Anchorage Warning Label |
| 500a13 | 269004160 | Guide |
| 500a14 | 243162060 | Hex. Flange Screw M6.81 x 20 |
| 500a2 | 269003492 | Locator Rod |
| 500a3 | 705000321 | Oval Washer |
| 500a4 | 269003483 | Gutter |
| 500a5 | 269003502 | Rubber Stopper |
| 500a6 | 295101126 | Lever Latch Service Kit |
| 500a7 | 219905993 | Lever Decal |
| 500a8 | 269003311 | Seat Anchorage |
| 500a9 | 250001154 | Torx Head M8 X 50 S.GRIP |
| 500b | 269003224 | Seat Cushion Ass'y |
| 500c | 269003609 | LH Overmolded Support |
| 500d | 269003764 | RH Overmolded Support |
| 500f | 269003765 | Support Trim |
| 500g | 250000234 | Torx Screw M6 X 20, Stainless |
| 500h1 | 232561200 | Brass Elastic Stop Nut M6 |
| 500j | 269003603 | Tilting Backrest Ass'y |
| 500k | 250000827 | Torx Screw Truss Cone HD.M6X50 |
| 500m | 250200044 | Flat Washer M6 X 25 |
| 500n1 | 232561200 | Brass Elastic Stop Nut M6 |
| 500p | 234062100 | Flat Washer 6 mm |
| 500q | 269003892 | Backrest Stopper |
| 500r | 250001119 | Screw K40 X 10 |
| 500s | 269003895 | Stopper |
| 500t | 219906226 | Bute File Decal |
| 600a | 269003315 | Corner Table Base |
| 600b | 269003533 | Top Corner Table |
| 600c | 250000879 | Plastite Torx Screw M6.81X30 |
| 600d | 243162060 | Hex. Flange Screw M6.81 x 20 |
| 600f | 269003492 | Locator Rod |
| 600g | 269003502 | Rubber Stopper |
| 600h | 295101126 | Lever Latch Service Kit |
| 600j | 219905993 | Lever Decal |
| 600k | 269003311 | Seat Anchorage |
| 600m | 250001154 | Torx Head M8 X 50 S.GRIP |
| 600n1 | 233181600 | Hex. Flange Nut M8 |
| 600p | 250200130 | Flat Washer 8 mm |
| 600q | 269004160 | Guide |
| 600r | 243162060 | Hex. Flange Screw M6.81 x 20 |
| 600s | 219905883 | Seat Anchorage Warning Label |
| 610 | 269003525 | Table Trim Ass'y |
| 620 | 269003645 | Cup Holder |
