| Ref | Part Number | Description |
|---|
| 1 |
5008160 |
LOGEMENT DE ROULEMENT & JOINT This part replaces 0387023. |
| 4 |
0321512 |
CRADLE, Clutch dog |
| 7 |
0322080 |
GEAR, Reverse This part replaces 0319625. |
| 8 |
0386418 |
PROPELLEER SHAFT |
| 9 |
0323278 |
SPRING, Detent This part replaces 0320217. |
| 11 |
0319565 |
SHIFTER, Clutch dog |
| 14 |
0388125 |
GEAR & BUSHING ASSY., Fwd This part replaces 0386452. |
| 16 |
0322079 |
PINION, Driveshaft This part replaces 0319501. |
| 17 |
0319656 |
THRUST WASHER, Bearing |
| 18 |
0386483 |
THRUST BEARING, Pinion |
| 19 |
0319667 |
THRUST WASHER |
| 20 |
0389729 |
GEARCASE, Bearing & seal This part replaces 0388258. |
| 21 |
0387861 |
HOUSING, Brg. & seal assy. |
| 23 |
0321459 |
OIL RETAINER, Housing |
| 24 |
0909140 |
O RING, Retainer backup |
| 25 |
0301877 |
O RING SHIFT ROD |
| 26 |
0320204 |
BUSHING, Shift rod |
| 27 |
0320208 |
WASHER, Seal |
| 33 |
0320118 |
LEVER, Shifting |
| 40 |
0319685 |
THRUST WASHE,Rear |
| 41 |
0319686 |
THRUST WASHER, Front |
| 42 |
0304081 |
CONNECTOR 5 " EXTENSION KIT |
| 45 |
0308707 |
SCREW |
| 45 |
0909533 |
SCREW, Pressure relief valve cover This part replaces 0316357. |
| 47 |
0322077 |
WATER TUBE, Standard |
| 47 |
0322078 |
WATER TUBE, Long |
| 49 |
0319678 |
SHIFT ROD, Lower std |
| 49 |
0319679 |
SHIFT ROD, Lower Long |
| 50 |
0319629 |
DRIVESHAFT, Std. |
| 50 |
0319630 |
DRIVESHAFT, Long |
| 51 |
0312978 |
SCREEN, Ground plt to intmd hsg |
| 52 |
0317078 |
KEY, Impeller |
| 55 |
0378891 |
IMPELLER ASSY. |
| 56 |
0322260 |
IMPELLER HOUSING |
| 56 |
0388456 |
IMPELLER HOUSING & PLATE |
| 57 |
0322259 |
PLATE, Impeller housing |
| 59 |
0319890 |
THRUST BUSHING, Prop |
| 60 |
0326692 |
SPACER, Impeller housing This part replaces 0322408. |
| 65 |
0387320 |
PROPELLER 11 1/4 X 7 AL |
| 65 |
0387525 |
PROPELLER 10 1/2 X 11 SST |
| 65 |
0387526 |
PROPELLER 11 X 9 SST |
| 65 |
0765048 |
PROPELLER, Aluminum, 3 x 11 in. x 9 P This part replaces 0386317. |
| 65 |
0765049 |
PROPELLER This part replaces 0386637. |
| 65 |
0778863 |
PROPELLER This part replaces 0386933. |
| 68 |
0387059 |
CHROME PUMP KIT |
| 68 |
0388257 |
CHROME PUMP KIT |
| 69 |
0387074 |
WATER PUMP REPAIR KIT |
| 69 |
0388256 |
WATER PUMP REPAIR KIT |
| 0317178 |
0317178 |
O RING |
| 0386992 |
0386992 |
EXTENSION KIT ASSY |
| 0388259 |
0388259 |
GEARCASE ASSY. |
